Dahua HAC-ME1200D-LS - Dome analog HD kamera

Markaya göre filtrele

Dahua HAC-ME1200D-LS - Dome analog HD kamera
Dahua

Dahua HAC-ME1200D-LS - Dome analog HD kamera

Model kodu
HAC-ME1200D-LS
Sistem
Kamera sistemi
Kategori
Dome analog HD kamera

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

2MP HDCVI Active Deterrence Camera * The parameters and datasheets below can only be applied to 1200-S5 series. > Max 30 fps@1080p

Teknik özellikler

Image Sensor 2MP CMOS
Max. Resolution 1920 (H) × 1080 (V)
Pixel 2MP
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25 s–1/100,000 s NTSC: 1/30 s–1/100,000 s
Min. Illumination 0.02 Lux/F2.0, 30 IRE, 0 Lux IR on
S/N Ratio > 65 dB
Illumination Distance 30 m (98.4 ft)
Illuminator On/Off Control Auto
Illuminator Number 1 (IR light)
Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360°
Lens Type Fixed-focal
Lens Mount M12
Focal Length 2.8 mm; 3.6 mm
Max. Aperture 2.8 mm: F2.0 3.6 mm: F2.0
Field of View 2.8 mm: H: 100°; V: 53°; D: 120° 3.6 mm: H: 83°; V: 44°; D: 99°
Close Focus Distance 2.8 mm: 0.6 m (2.0 ft) 3.6 mm: 0.8 m (2.6 ft)
Video Frame Rate CVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps AHD: PAL: 1080p@25 fps; NTSC: 1080p@30 fps TVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps CVBS: PAL: 960H; NTSC: 960H
Resolution 1080p (1920 ×1080); 960 H (960 × 576/960 × 480)
Day/Night Auto (ICR)
BLC BLC/HLC/DWDR
WDR DWDR
White Balance Auto/Area WB
Gain Control Auto
Noise Reduction 2D NR
Smart Illumination Yes
Mirror Yes
Privacy Masking Off/On (8area,rectangle)
Detection Mode Pyroelectric infrared sensor
Max. Detection Range 10 m (32.8 ft), 110°
Recommended Installation Height 2.2 m–3 m (7.2 ft-9.8 ft)
Recommended Working Temperature –10 °C to 50 °C (14 °F to 122 °F)
White Light Warning lighting/flash; Alert Duration: 5 s–60 s; flash Freq: low/medium/high
Sound Warning Audio 1/2/3; Volume: high/medium/low; duration: 5 s–60 s; 110 dB
Certifications CE (EN55032:2015, EN61000-3-2:2014, EN61000- 3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) IEC 62368-1:2014 (Second Edition)
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power Supply DC12V±30%
Power Consumption Max 4.9 W (12 V DC, IR on)
Operating Temperature –40 °C to +60 °C (–40 °F to 140 °F); < 95% (non-condensation)
Storage Temperature –40 °C to +60 °C (–40 °F to 140 °F); < 95% (non-condensation)
Protection IP67
Casing Cover: Metal Rear: Plastic
Camera Dimensions 168.8 mm × 79.0 mm × 79.0 mm (6.65" × 3.11" × 3.11")
Net Weight 0.32 kg (0.71 lb)
Gross Weight 0.45 Kg (0.99 lb)

Dokümanlar

Data Sheet
