Dahua HAC-ME1500B-L - Dome analog HD kamera

Markaya göre filtrele

Dahua HAC-ME1500B-L - Dome analog HD kamera
Dahua

Dahua HAC-ME1500B-L - Dome analog HD kamera

Model kodu
HAC-ME1500B-L
Sistem
Kamera sistemi
Kategori
Dome analog HD kamera

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

5MP HDCVI Active Deterrence Camera > * The parameters and datasheets below can only be applied to 1500-S2 series. > * In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version. > Max 25 fps@5MP (16:9 video output)

Teknik özellikler

Image Sensor 5MP
Max. Resolution 1/2.7"CMOS
Pixel 2880(H)×1620(V)
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25 s–1/100,000 s NTSC: 1/30 s–1/100,000 s
S/N Ratio 0.005 Lux/F1.6, 30IRE, 0 Lux IR on
Min. Illumination > 65 dB
Illumination Distance 30 m (98.4 ft)
Illuminator On/Off Control Auto
Illuminator Number 1(IR light)
Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360°
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8 mm; 3.6 mm
Max. Aperture F1.6
Field of View 2.8 mm: H: 113°; V: 60°; D: 132° 3.6 mm: H: 90°; V: 48°; D: 104°
Iris Type Fixed iris
Close Focus Distance 2.8 mm: 1.0 m 3.6 mm: 1.5 m
Frame Rate CVI: PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps; NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps AHD: PAL: 4M@25 fps; NTSC: 4M@30 fps TVI: PAL: 4M@25 fps; NTSC: 4M@30 fps CVBS: PAL: 960H; NTSC: 960H
Resolution 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 ×1080); 960 H (960 × 576/960 × 480)
Day/Night Auto switch by ICR
BLC BLC/HLC/DWDR
WDR DWDR
White Balance Auto/Area WB
Gain Control Auto
Noise Reduction 2D NR
Smart IR Yes
Mirror Off/On
Privacy Masking Off/On (8 area, rectangle)
Detection Mode Pyroelectric infrared sensor
Max. Detection Range 10 m(32.8 ft), 110°
Recommended Installation Height 2.2 m–3 m (7.2 ft-9.8 ft)
Recommended Working Temperature –10 °C to 50 °C (14 °F to 122 °F)
White Light Warning lighting/flash; Alert Duration: 5 s–60 s; flash Freq: low/medium/high
Certifications CE (EN55032:2015, EN61000-3-2:2014, EN61000- 3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) IEC 62368-1:2014 (Second Edition)
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power Supply DC12 V±30%
Power Consumption Max 4.5 W (12 V DC, IR on)
Operating Temperature –40 °C to +60 °C (–40 °F to 140 °F); < 95% (non-condensation)
Storage Temperature –40 °C to +60 °C (–40 °F to 140 °F); < 95% (non-condensation)
Protection Grade IP67
Casing Cover: Metal Rear: Plastic
Camera Dimensions 146.6 mm × 72.4 mm × 83.0 mm (5.77" × 2.85" × 3.27")
Net Weight 0.24 kg (0.53 lb)
Gross Weight 0.35 Kg (0.77 lb)

Dokümanlar

Data Sheet

Bu ürünü satan firmalar

3 firma
AMERKEZ TEKONOLJİ VE YAZILIM
Küçükçekmece, İstanbul
BİGES GÜVENLİ HAYAT TEKNOLOJİLERİ A.Ş.
Şişli, İstanbul
OKİSAN GÜVENLİK TEKNOLOJİLERİ SAN. VE TİC. A.Ş.
Şişli, İstanbul
