Dahua IPC-HFW5541T-ASE-OPAT - Bullet IP kamera
Dahua

Dahua IPC-HFW5541T-ASE-OPAT - Bullet IP kamera

Model kodu
IPC-HFW5541T-ASE-OPAT
Sistem
Kamera sistemi
Kategori
Bullet IP kamera

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

5 MP DHOP IR-Bullet Box Network Camera > 5 MP 1/2.7" CMOS image sensor, low luminance, and high definition image. > Outputs max. 5 MP (2592 × 1944)@20 fps and supports 4 MP (2688 × 1520)@25/30 fps. > H.265 codec, high compression rate, ultra-low bit rate. > Built-in IR LED; the max. IR illumination distance is 30 m. > ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments > Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes. > Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection. > Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card. > 12 VDC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes. > IP67 protection.

Teknik özellikler

Computing Power 1T computing power for enhanced performance
Flash 58M
System Memory 380M
Multimedia Memory 256M
DHOP Partners A.I.Tech, ACIC, Grekkom, Kobi, Retailflux, Siteeye, TechnoAware, etc. ( https://depp.dahuasecurity.com/OpenPlatform)
Image Sensor 1/2.7" CMOS
Max. Resolution 2592 (H) × 1944 (V)
ROM 128 MB
RAM 1 GB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.002 [email protected] (Color,30 IRE) 0.0002 [email protected] (B/W,30 IRE) 0 lux (Illuminator on)
S/N Ratio > 56 dB
Illumination Distance 30 m (98.43 ft) (IR)
Illuminator On/Off Control Auto, manual
Illuminator Number 4 (IR LED)
Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360°
Lens Type Fixed-focal
Lens Mount M12
Focal Length 2.8 mm
Max. Aperture F1.6
Field of View Horizontal: 98°× Vertical: 71°× Diagonal: 129°
Iris Control Fixed
Close Focus Distance 1.1 m (3.6 ft)
Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec Smart H.265+;Smart H.264+
Video Frame Rate Main stream: 2592 × 1944@(1 fps–20 fps)/2688 × 1520 @(1 fps–30 fps) Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps) Third stream: 1920 × 1080@(1 fps–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability 3 streams
Resolution 5M (2592 × 1944); 4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); VGA (640 x 480); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 3 kbps–20480 kbps H.265: 3 kbps–20480 kbps
Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
Scene Self-adaptation (SSA) Yes
White Balance Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control Auto; Manual
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Defog Yes
Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror Yes
Privacy Masking 8 areas
Audio Compression PCM; G.711a; G.711Mu; G.726; G.723
Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; scene changing; audio detection; voltage detection; external alarm; security exception
Network Port RJ-45 (10/100 Enhancement Base-T)
SDK and API Yes
Cyber Security Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Network Protocol IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone;DHOP SDK
User/Host 20 (Total bandwidth: 72 M)
Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser IE: IE8/9/11 Chrome Firefox
Management Software Smart PSS; DSS
Certification CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC:47 CFR FCC Part 15, Subpart B
Audio Input 1 channel (RCA port)
Audio Output 1 channel (RCA port)
Alarm Input 1 channel in: 5mA 3V–5 VDC
Alarm Output 1 channel out: 300 mA 12 VDC
Power Supply 12 VDC/PoE (802.3af)/ePoE
Power Consumption Basic power consumption: 2.4W (12 VDC); 3W (PoE) Max. power consumption (max. stream + IR LED): 7.1W (12 VDC); 8.4W (PoE)
Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity ≤ 95%
Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Protection IP67
Casing Metal + plastic
Product Dimensions 244.1 mm × 79.0 mm × 75.9 mm (9.6" × 3.1" × 3") (L × W × H)
Net Weight 0.815 kg (1.8 lb)
Gross Weight 1.08 kg (2.4 lb)

Dokümanlar

Data Sheet
