Dahua SD29404DB-GNY - PTZ IP kamera

Markaya göre filtrele

Dahua SD29404DB-GNY - PTZ IP kamera
Dahua

Dahua SD29404DB-GNY - PTZ IP kamera

Model kodu
SD29404DB-GNY
Sistem
Kamera sistemi
Kategori
PTZ IP kamera

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

4MP 4x IR WizSense Network PTZ Camera > 1/2.8" 4Megapixel CMOS. > Max. 25/30fps@4MP. > IR distance up to 50 m. > 4x optical zoom. > WDR. > SMD 3.0. > Built-in Mic. > PoE.

Teknik özellikler

Image Sensor 1/2.8" CMOS
Pixel 4 MP
Max. Resolution 2560 (H) × 1440 (V)
ROM 128 MB
RAM 512 MB
Electronic Shutter Speed 1/1s–1/30,000s
Scanning System Progressive
Min. Illumination Color: 0.005 [email protected] B/W: 0.0005 [email protected] 0 lux (IR light on)
Illumination Distance 50 m (164.04 ft) (IR)
Illuminator On/Off Control Zoom Prio; Manual; Auto; Off
Illuminator Number 2 (IR)
Focal Length 2.8 mm–12 mm
Max. Aperture F1.6–F3.0
Field of View H: 94.9°–30.1°; V: 51°–17.1°; D: 112.3°–34.6°
Optical Zoom 4×
Focus Control Auto; semi-auto; manual
Close Focus Distance 1.5 m (4.92 ft)
Iris Control Fixed
Pan/Tilt Range Pan: 0° to 360° not endless; Tilt: 0° to +90°
Manual Control Speed Pan: 0.1°/s–100°/s; Tilt: 0.1°/s–60°/s
Preset Speed Pan: 100°/s; Tilt: 60°/s
Preset 300
Tour 8 (up to 32 presets per tour)
Pattern 5
Scan 5
Power-off Memory Yes
Idle Motion Pattern; Preset; Scan; Tour
PTZ Protocol DH-SD4
PTZ Locked Yes
IVS (Perimeter Protection) Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification
Face Detection Supports face detection,snapshot, and face enhancement; Supports face cutout: Face, one-inch photo; Capturing strategies include real-time capturing and quality first.
SMD Yes
Video Compression H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+
Streaming Capability 3 streams
Resolution 4M (2560 × 1440); 3M (2304 × 1296); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Video Frame Rate Main stream: 4M/3M/1080p/1.3M/720p@(1-25/30 fps) Sub stream 1: D1/VGA/CIF@(1-25/30 fps) Sub stream 2: 720p@(1-25/30 fps)
Bit Rate Control CBR/VBR
Video Bit Rate H264: 24 Kbps–13056 Kbps H265: 9 Kbps–7936 Kbps
Day/Night ICR: Auto; color; B/W Electronic: Auto; color; B/W
BLC Yes
WDR 120 dB
HLC Yes
White Balance Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Gain Control Auto; manual; gain prio
Noise Reduction 2D NR; 3D NR
Motion Detection Yes
Region of Interest (RoI) Yes
Image Stabilization Electronic
Defog Electronic
Digital Zoom 16 ×
Image Rotation 180°
S/N Ratio ≥ 55 dB
Privacy Mask Up to 24 areas can be set, with up to 8 areas in the same view; 8 colors available
Audio Compression G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; PCM
Network Port RJ-45 (10/100 Base-T)
Network Protocol FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; SMB; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP
Interoperability CGI; SDK; ONVIF (Profile S&G&T); P2P
Streaming Method Unicast/Multicast
User/Host 20 (total bandwidth: 64 M)
Storage ONVIF (Profile S&G&T); P2P; CGI; SDK
Browser IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions
Management Software DMSS; DSS Pro
Mobile Client iOS; Android
Certifications CE: EN55032/EN 50130-4/EN 55035/EN61000-3-2/EN61000-3-3
Audio Input 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive))
Audio Output 1 channel (LINE OUT,bare wire)
Alarm Input 2 (on-off value input: 0–5 VDC)
Alarm Output 1
Alarm Linkage Capture; recoding; send email; preset; tour; pattern; alarm digital output; audio
Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; power exception detection
Power Supply 12 VDC, 2A ± 10% (optional) PoE (802.3af)
Power Consumption Basic: 5 W Max: 10 W (illuminator+PTZ)
Operating Temperature –30 °C to +50 °C (–22 °F to +122 °F)
Operating Humidity ≤ 95%
Protection 6000V lightning proof; surge protection; voltage transient protection
Product Dimensions 117.4 mm × Φ132.1 mm (4.62" × Φ5.20")
Net Weight 0.713 kg (1.57 lb)
Gross Weight 1.0 kg (2.20 lb)

Dokümanlar

Data Sheet
