Hikvision AE-DI2032-G40(Overseas)

Markaya göre filtrele

Hikvision AE-DI2032-G40(Overseas)
Hikvision

Hikvision AE-DI2032-G40(Overseas)

Model kodu
AE-DI2032-G40(Overseas)
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Up to 1080P resolution. Supports 3-ch video, 1-ch audio (CH 1). Supports GPS and speed overlay on picture. Supports built-in Wi-Fi module, supports Wi-Fi AP. Supports 4G network. Supports dual-TF card storage and recording overwrite. Supports preview, playback and editing parameters via APP. Supports built-in Gyroscope. Compatible with 2-ch 720P TVI extended camera or 1-ch 1080P TVI extended camera. DSM alarm supports driving safety monitoring etc.. Easy installation and operation. Low power consumption and high performance. Supports HCP Platforms

Teknik özellikler

Image Sensor 1/2.7'' Progressive Scan CMOS
Shutter Speed 1/3 s to 1/100, 000 s
Min. Illumination 0.01 Lux @ (AGC ON)
Focal Length Fixed focal lens, 2.1mm
Aperture F2.1
Lens Mount M12
FOV Horizontal FOV: 127° Vertical FOV: 73° Diagonal FOV: 137°
Audio Input 1-channel audio
Video Input 3-channel video (default: 1 channel; extension: 2 channels)
Video Compression H.265,H.264
Audio Compression G.711ulaw,G.711alaw,AAC
Main Stream CH1: 25fps 1080P 1920 × 1080 (default) 25fps 720P 1280 × 720 CH2~CH3: 25fps 720P 1280 × 720 (default)
Sub- Stream CH1: 25fps 720P 1280×720 25fps 480P 640×480 (default) CH2~CH3: 25fps 480P 640×480 (default)
Built-in Mic Omnidirectional pickup, frequency response 50-20000 Hz
Built-in Speaker Max 1.5 W, with adjustable volume, not less than 70 dB at 1 m distance
Wi-Fi Frequency 2.4 GHz
Positioning GPS (Global Positioning System) GLONASS (Global Navigation Satellite System)
SNR 37.5 dB
Wide Dynamic Range Supports WDR
Image Settings Adjustable brightness, chroma, contrast, color saturation, and sharpness
OSD Date, Time, GPS, Speed, etc.
Alarm Input 2
SIM Card Slot 1, Industry Micro SIM, Plug-in type
Power Interface 1, 8-pin BM Male Terminal
Reset Key 1, Pinhole button
RS-232 1
Dial-up Europe： FDD-LTE: B1, B3, B5, B7, B8, B20 TDD-LTE: B38, B40, B41 UMTS: B1, B5, B8 GSM/GPRS/EDGE: 900/1800 MHz Latin America : FDD-LTE: B1, B2, B3, B4, B5, B7, B8, B28, B66 TDD-LTE: B40 UMTS: B1, B2, B5, B8 GSM/GPRS/EDGE: 850/900/1800/1900 MHz Warning: The device requires industrial SIM card (MP2). The ordinary SIM card (MP1) is prohibited. We are not responsible for any problem caused by the use of any ordinary SIM card.
Wi-Fi Protocol 802.11 b/g/n
Driving Status Monitoring (DSM) Phone Call,Smoking,Inattenention,Fatigue Driving, Video Occlusion, Infrared Blocking Sunglasses, Not Wearing Seat Belt
Advanced Driving Assistance System (ADAS) Forward Collision Warning (FCW) Pedestrian Collision Warning (PCW) Lane Departure Warning(LDW) Traffic Sign Recognition (TSR) Headway Monitoring Warning (HMW) Traffic Light Detection(TLD) Forward Car Leaving(FCL)
System Embedded Linux
Language Currently only supports English *The language includes APP interface language and voice reminder.
Storage Dual TF Card (up to 512GB for each) Class10 or above is recommended
Sensor Six-axis G-Sensor *Harsh acceleration, Harsh deceleration and Harsh cornering
Image Format JPEG
Indicator Positioning Status Indicator (GNSS) Off: no positioning signal Steady blue: the positioning signal is normal Recording Status Indicator(REC) Off: The built-in or extended camera stops / fails Steady blue: The built-in or extended camera is recording normally Network Status Indicator (4G) Off: No 4G signal Steady blue: 4G signal and the platform connection normal Flashing blue: 4G signal normal but no platform connection Wi-Fi Status Indicator Off: Wi-Fi AP closed Steady blue: Wi-Fi AP open and APP connection normal Flashing blue: Wi-Fi AP open but no APP connection
Protection Level IP4X *The dashcam is not waterproof
Power Supply DC 11.8 V~16 V/23.5 V-36 V ( P＜12W )
Product Dimension 123.0 mm×85.0 mm×38.9 mm (4.8"×3.4"×1.5")
With Package Dimension 223 mm×153 mm×63 mm (8.8"×6.0"×2.5")
Operating Temperature -20°C to 60°C (-4°F to 140°F)
Operating Humidity 10% to 95% (non-condensing)
Net Weight Approx. 270 g (0.6 lb.)
With Package Weight Approx. 900 g (2.0 lb.)

Dokümanlar

Data Sheet - Industry Dashcam Quick Start Guide - Industry Dashcam User Manual - Industry Dashcam 【Release Note】Dashcam AE-DI2032-G40 V5.1.2 - Industry Dashcam
