Hikvision DS-2CD6984G1/VR-U/NFC - Panoramik/fisheye IP kamera

Markaya göre filtrele

Hikvision DS-2CD6984G1/VR-U/NFC - Panoramik/fisheye IP kamera
Hikvision

Hikvision DS-2CD6984G1/VR-U/NFC - Panoramik/fisheye IP kamera

Model kodu
DS-2CD6984G1/VR-U/NFC
Sistem
Kamera sistemi
Kategori
Panoramik/fisheye IP kamera

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

High quality imaging with 8 MP resolution for each lens.. 4 lenses cover up to 720° splicing image to present all scenes that covered by the camera.. Efficient H.265 compression technology.. Support on-board storage up to 512 GB (SD card slot). 1 FC fiber optical interface, SFP module, single mode, 20 km transmission distance. Water and dust resistant (IP66)

Teknik özellikler

Image Sensor 1/1.8" Progressive Scan CMOS
Max. Resolution Panorama: 7680 × 3840, Original: 3840 × 2160
Min. Illumination Color: 0.002 Lux @ (F1.2, AGC ON)
Shutter Time 1 s to 1/100,000 s
Lens Type Fixed focal lens, 2 mm
Focal Length & FOV 2 mm, horizontal FOV 360°, vertical FOV 360°
Aperture F2.0
DORI D: 46.0 m, O: 18.3 m, R: 9.2 m, I: 4.6 m
Main Stream Panorama: 50 Hz: 25 fps (7680 × 3840, 5760 × 2880, 3840 × 1920) 60 Hz: 30 fps (7680 × 3840, 5760 × 2880, 3840 × 1920) Original: 50 Hz: 25 fps (3840 × 2160) 60 Hz: 30 fps (3840 × 2160)
Video Compression Main stream: H.265/H.264/H.264+/H.265+
Video Bit Rate 32 Kbps to 64 Mbps
H.264 Type High Profile,Baseline Profile,Main Profile
H.265 Type Main Profile
Bit Rate Control CBR,VBR
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps(AAC-LC)/8 to 48 Kbps (PCM)
Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, AES128/256
Network Storage NAS (NFS, SMB/CIFS)
Client iVMS-4200,Hik-Connect
Simultaneous Live View Up to 20 channels
API ONVIF, ISAPI
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host Up to 32 users 3 user levels: administrator, operator, and user
Web Browser Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Settings saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser
Wide Dynamic Range (WDR) Digital WDR
Image Enhancement BLC,HLC
Ethernet Interface 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port,1 1000M FC fiber optical interface
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Microphone 1 built-in microphone
Reset Key Yes
Indicator Yes
Fiber Optical 1 FC fiber optical interface, SFP module, single mode, 20 km transmission distance, 1310 nm (TX) and 1550 nm (RX), 1250 Mbps transmission rate
Basic Event exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Linkage notify surveillance center,send email
Power 12 VDC ± 25%, 1.2 A, max. 14.4 W, 24 VAC ± 25%, 0.95 A, max. 14 W,three-core terminal block
Material Metal and plastic
Dimension 189 mm × 90.3 mm × 90.3 mm (7.4" × 3.6" × 3.6")
Package Dimension 349 mm × 159 mm × 153 mm (13.74" × 6.26" × 6.02")
Weight Approx. 1170 g (2.58 lb.)
With Package Weight Approx. 1360 g (3 lb.)
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function Heartbeat,mirror,flash log,password reset via email,pixel counter,one-key reset,password protection,anti-banding
Protection IP66: IEC 60529:1989+AMD1:1999+AMD2:2013

Dokümanlar

Data Sheet - 32 MP 360° VR Network Camera
