Hikvision DS-2CFSP4/4G

Model kodu: DS-2CFSP4/4G
Sistem: Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Support AOV Mode：24/7 video recording. 8 W solar panel and 9000 mAh battery. Support 4G LTE data transmission. Smart Hybrid Light: 30 m white light and IR. Motion Detection 2.0: Support person and vehicle detection. Built-in microphone and speaker, support two-way audio. Water and dust resistant (IP66). Smart Tracking: PT Camera achieves person tracking with Motion Detection 2.0

Teknik özellikler

Image Sensor	1/3" Progressive Scan CMOS
Max. Resolution	2560 × 1440
Min. Illumination	Color: 0.005 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
Shutter Time	1 s to 1/100,000 s
Day & Night	IR cut filter
Lens Type	Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV	2.8 mm, horizontal FOV 95.7°, vertical FOV 51.7°, diagonal FOV 113.7° 4 mm, horizontal FOV 79.6°, vertical FOV 43.2°, diagonal FOV 93.2°
Lens Mount	M12
Iris Type	Fixed
Aperture	F1.28
Movement Range (Pan)	0° to 340°
Movement Range (Tilt)	0° to 80°
Pan Speed	Up to 20°/s
Tilt Speed	Up to 25°/s
DORI	2.8 mm D: 63.9 m, O: 25.4 m, R: 12.8 m, I: 6.4 m 4 mm D: 77.6 m, O:30.8 m, R: 15.5 m, I: 7.8 m
Supplement Light Type	IR,White Light
Supplement Light Range	Up to 30 m
Smart Supplement Light	Yes
IR Wavelength	850 nm
Main Stream	50 Hz: 12.5 fps {2560 x 1440, 1920 × 1080, 1280 × 720) 60 Hz: 15 fps (2560 x 1440, 1920 × 1080, 1280 × 720)
Video Bit Rate	32 Kbps to 8 Mbps
H.265 Type	Main Profile
Bit Rate Control	CBR,VBR
Audio Compression	G.711ulaw
Audio Bit Rate	64 Kbps(G.711ulaw）
Audio Sampling Rate	8 kHz/16 kHz
Environment Noise Filtering	Yes
Simultaneous Live View	Up to 6 channels
API	ISAPI
User/Host	Up to 32 users 3 user levels: administrator, operator, and user
Client	Hik-Connect
Standard	LTE-FDD,LTE-TDD,UMTS
Frequency	EU:LTE-FDD: B1/3/5/7/8/20/28 LA:LTE-FDD: B2/3/4/5/7/8/28/66
Uplink and Downlink Data Rate	EU: Cat 1, uplink: 5.1 Mbps, downlink: 10.3 Mbps, IN: Cat 1, uplink: 5.1 Mbps, downlink: 10.3 Mbps, LA: Cat 1, uplink: 5.1 Mbps, downlink: 10.3Mbps, NA: Cat 4, uplink: 50 Mbps, downlink:150 Mbps, JP: Cat 4, uplink: 50 Mbps, downlink:150 Mbps
SIM Card Type	Nano SIM
Image Settings	Saturation,brightness,contrast,sharpness,white balance
Day/Night Switch	Day,Night,Auto,Schedule
Image Enhancement	BLC,HLC,3D DNR
Wide Dynamic Range (WDR)	Digital WDR
On-Board Storage	Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Microphone	1 built-in microphone
Built-in Speaker	1 built-in speaker
Reset Key	Yes
Basic Event	Motion detection (support alarm triggering by specified target types (human and vehicle))
Linkage	notify surveillance center,trigger recording,trigger capture,audible warning,Upload to memory card
Power	12 V, 0.75 A
Material	Plastic
Dimension	208 mm × 131 mm × 282.7 mm (8.2" × 7.0" × 11.1")
Package Dimension	386 mm × 201 mm × 225 mm (15.2" × 7.9" × 8.9")
Weight	Approx. 850 g (1.9 lb.)
With Package Weight	Approx. 5400 g (11.9 lb.)
General Function	Mirror,flash log
Storage Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions	0 °C to 50 °C (32 °F to 122 °F). Humidity 95% or less (non-condensing)
Battery Type	Lithium
Battery Voltage	DC 6 V to DC 8.4 V
Capacity	9000 mAh (3.7 V)
Max. Charging Voltage	8.4 V
Max. Output Voltage	8.4 V
Operating Temperature	Charging: 0 °C to 45 °C (32 °F to 113 °F) Discharging: -20 °C to 55 °C (-4 °F to 131 °F)
Battery Life	More than 800 cycles
RF	CE-RED: EN 301489-1 V2.1.1 (BT or 2.4G), EN 301489-17 V3.1.1 (BT or 2.4G), EN 300328 V2.1.1 (BT or 2.4G), EN 62311: 2008 (BT or 2.4G) *CE certification is only for the device sold in the European region.
EMC	CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety	CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Environment	CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection	IP66: IEC 60529-2013
