Hikvision DS-2CFW06-P - Panoramik/fisheye IP kamera

Markaya göre filtrele

Hikvision DS-2CFW06-P - Panoramik/fisheye IP kamera
Hikvision

Hikvision DS-2CFW06-P - Panoramik/fisheye IP kamera

Model kodu
DS-2CFW06-P
Sistem
Kamera sistemi
Kategori
Panoramik/fisheye IP kamera

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

High quality imaging with 6 MP resolution. Support Person and Vehicle Detection. Smart Hybrid Light: advanced technology with long range. Efficient H.265+ compression technology. Provide real-time security via built-in two-way audio. Water and dust resistant (IP67). 180° Field of view. Active strobe light and audio alarm to warn intruders off

Teknik özellikler

Image Sensor 1/2.5" Progressive Scan CMOS
Max. Resolution 3632 × 1632
Shutter Time 1 s to 1/100,000 s
Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 360°,tilt: 0° to 180°,rotate: 0° to 360°
Lens Type Fixed focal lens, 2.8 mm
Focal Length & FOV 2.8 mm, horizontal FOV 180°, vertical FOV 77°
Iris Type Fixed
Lens Mount M12
Aperture F1.6
DORI 2.8 mm, D: 42 m, O: 16 m, R: 8 m, I: 4 m
Supplement Light Range IR: up to 30 m White Light: up to 30 m
Smart Supplement Light Yes
Supplement Light Type IR,White Light
IR Wavelength 850 nm
Main Stream 50 Hz: 20 fps (3632 × 1632,2688 × 1200,1824 × 816) 60 Hz: 20 fps (3632 × 1632,2688 × 1200,1824 × 816)
Sub-Stream 50 Hz: 20 fps (960 × 432) 60 Hz: 20 fps (960 × 432)
H.265 Type Main Profile
Video Compression Main stream: H.265 Sub-stream: H.265
Video Bit Rate 32 Kbps to 4 Mbps
H.264 Type Baseline Profile,Main Profile,High Profile
Bit Rate Control CBR,VBR
Region of Interest (ROI) 1 fixed region for main stream
Scalable Video Coding (SVC) H.264 and H.265 encoding
Audio Compression G.711/AAC-LC
Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 to 64 Kbps (AAC-LC)
Audio Type Mono sound
Environment Noise Filtering Yes
Audio Sampling Rate 8 kHz/16 kHz
Web Browser Plug-in required live view: IE 11, Local service: Chrome 91+, Firefox 88+, Edge 91+
API ISAPI,SDK
Client iVMS-4200, Hik-Connect *Wi-Fi connection with Hik-Connect directly is not possible
Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Simultaneous Live View Up to 6 channels
Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IPv4, IPv6, IGMP, UDP, QoS
User/Host Up to 32 users 3 user levels: administrator, operator, and user
Encryption Mode WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK
Wi-Fi Protocol IEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.11ax
Frequency Range 2.4 GHz to 2.4835 GHz
Channel Bandwidth 20/40 MHz,Only 802.11n supports 40 MHz
Modulation 802.11b: DBPSK, DQPSK, CCK 802.11g: BPSK, QPSK, 16QAM, 64QAM 802.11n: BPSK, QPSK, 16QAM, 64QAM 802.11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM
Transfer Rate 802.11b: up to 11 Mbps 802.11g: up to 54 Mbps 802.11n: up to 150 Mbps 802.11ax: up to 114 Mbps
Wireless Range Up to 120 m (The performance varies based on actual environment)
Antenna 1 Antenna
Day/Night Switch Day,Night,Auto,Schedule
Image Enhancement BLC,HLC,3D DNR
Wide Dynamic Range (WDR) 120 dB
SNR ≥ 52 dB
Image Settings Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Privacy Mask 4 programmable polygon privacy masks
Built-in Microphone Yes,1 built-in microphone
Built-in Speaker Yes, 1 built-in speaker,Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB.
Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
Reset Key Yes
Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage Notify surveillance center, audible warning, strobe light flashing
Power 12 VDC ± 25%, 0.91 A, max. 11 W,Ø5.5 mm coaxial power plug,reverse polarity protection
Material Front cover: Metal, body: Plastic, bracket: Metal
Dimension 103.6 mm × 76 mm × 234.4 mm (4.08" × 2.99" × 9.23")
Package Dimension 344 mm × 144 mm × 93 mm (13.54" × 5.67" × 3.66")
With Package Weight Approx. 905 g (2.00 lb.)
Weight Approx. 650 g (1.43 lb.)
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language English, Ukrainian
General Function Heartbeat,anti-banding,password protection,password reset via email
Flashing Light White Light
Protection IP67: IEC 60529-2013
RF CE-RED：EN 301 489-17 V3.3.1,EN 301 489-1 V2.2.3,EN 300 328 V2.2.2,EN IEC 62311:2020
EMC CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
Safety CB: IEC 62368-1: 2014+A11
Environment CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

Bu ürünü satan firmalar

1 firma
TESAN İLETİŞİM A.Ş
Bahçelievler, İstanbul
