Hikvision DS-2DE2C200MWG-E - Hibrit kayıt cihazı

Markaya göre filtrele

Hikvision DS-2DE2C200MWG-E - Hibrit kayıt cihazı
Hikvision

Hikvision DS-2DE2C200MWG-E - Hibrit kayıt cihazı

Model kodu
DS-2DE2C200MWG-E
Sistem
Kamera sistemi
Kategori
Hibrit kayıt cihazı

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

High quality imaging with 2 MP resolution. Support Human Detection and Auto-tracking Lite. Smart Hybrid Light: advanced technology with long range. Hik-Connect cloud service and APP for remote management and views of device. Built-in microphone and speaker for real-time audio security. Built-in memory card slot, support microSD/SDHC/SDXC card, up to 512 GB. Water and dust resistant (IP66)

Teknik özellikler

Image Sensor 1/2.9" Progressive Scan CMOS
Max. Resolution 1920 × 1080
Min. Illumination Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0.005 Lux @ (F2.0, AGC ON),0 Lux with light
Focal Length 2.8 mm, 4 mm
FOV 2.8 mm, horizontal FOV 105°, vertical FOV 58°, diagonal FOV 123° 4 mm, horizontal FOV 81°, vertical FOV 44°, diagonal FOV 97°
Aperture F2.0
Supplement Light Type IR,White Light
Supplement Light Range White light distance: up to 30 m,IR distance: up to 30 m
IR Wavelength 850 nm
Movement Range (Pan) 0° to 345°
Movement Range (Tilt) 0° to 80°
Pan Speed Up to 25°/s
Tilt Speed Up to 20°/s
Main Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
Video Compression H.265, H.264, MJPEG
Video Bit Rate 32 Kbps to 8 Mbps
H.264 Type Baseline profile,Main profile,High profile
H.265 Type Main profile
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM//AAC-LC
Audio Bit Rate 16 Kbps (G.722.1)/64 Kbps (G.711)/32 to 192 Kbps (MP2L2)/16 Kbps (G.726)/16 to 64 Kbps (AAC-LC)/8 to 48 Kbps (PCM)
Audio Sampling Rate 8 kHz,16 kHz
Environment Noise Filtering Yes
Protocols IPv4/IPv6, HTTP, HTTPS, QoS, FTP, SMTP, UPnP, DNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour
API ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK
Image Settings Saturation, brightness, contrast, and sharpness adjustable by client software or web browser
Wide Dynamic Range (WDR) Digital WDR
Image Enhancement BLC, HLC, 3D DNR
Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
Built-in Microphone 1 built-in microphone
On-board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Speaker 1 built-in speaker
Basic Event Motion detection (support alarm triggering by specified target type (human)), video tampering alarm, exception
Linkage Upload to FTP/memory card, notify surveillance center, send email, trigger capture, audible warning, auto-tracking lite
Power 12 VDC ± 25%, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, 36 V to 57 V, 0.2 A to 0.3 A, max. 10.5 W
Dimension Camera dimension: 163.9 mm × 185.8 mm × 131.9 mm (6.45" × 7.31" × 5.19") With package dimension: 224 mm × 164 mm × 230 mm (8.82" × 6.46" × 9.06")
Weight Camera weight: 600 g (1.32 lb.) With package weight: 900 g (2.0 lb.)
Material Plastic
Operating Condition -30 °C to 40 °C (-22 °F to 104 °F). Humidity 90% or less (non-condensing)
General Function Mirror, password protection, watermark
EMC CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014)
Safety CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017)
Environment CE-RoHS (2011/65/EU),Reach (Regulation (EC) No 1907/2006)
Protection IP66 (IEC 60529-2013)
