Hikvision DS-2DE2C600MWG-E - Hibrit kayıt cihazı

Markaya göre filtrele

Hikvision DS-2DE2C600MWG-E - Hibrit kayıt cihazı
Hikvision

Hikvision DS-2DE2C600MWG-E - Hibrit kayıt cihazı

Model kodu
DS-2DE2C600MWG-E
Sistem
Kamera sistemi
Kategori
Hibrit kayıt cihazı

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

High quality imaging with 6 MP resolution. Support Human Detection and Auto-tracking Lite. Smart Hybrid Light: advanced technology with long range. Hik-Connect cloud service and app for remote management and views of devices. Built-in microphone and speaker for real-time audio security. Built-in memory card slot, support microSD/SDHC/SDXC card, up to 512 GB. Water and dust resistant (IP66)

Teknik özellikler

Image Sensor 1/2.4" Progressive Scan CMOS
Max. Resolution 3200 × 1800
Min. Illumination Color: 0.001 Lux @ (F1.6, AGC ON),B/W: 0.0005 Lux @ (F1.6, AGC ON),0 Lux with light
Focal Length 2.8 mm, 4 mm
FOV 2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127° 4 mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 97°
Aperture F1.6
Supplement Light Type IR,White Light
Supplement Light Range Up to 30 m
Smart Supplement Light Yes
IR Wavelength 850 nm
Movement Range (Pan) 0° to 345°
Movement Range (Tilt) 0° to 80°
Pan Speed Up to 25°/s
Tilt Speed Up to 20°/s
Main Stream 50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (3200 × 1800, 2688×1520, 1920 × 1080, 1280 × 720)
Sub-Stream 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression Main stream: H.265/H.264/Smart265/Smart264, Sub-stream: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 16 Mbps
H.264 Type Main profile,Baseline profile,High profile
H.265 Type Main profile
Audio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate 8 kHz/16 kHz
Environment Noise Filtering Yes
Protocols IPv4/IPv6, HTTP, HTTPS, QoS, FTP, SMTP, UPnP, DNS, DDNS, NTP, RTSP, RTP, RTCP, TCP/IP, UDP, DHCP, Bonjour
API ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK
Client iVMS-4200, Hik-Connect, HikCentral Professional, Hik-Partner Pro
Image Settings Saturation, brightness, contrast, and sharpness adjustable by client software or web browser
Wide Dynamic Range (WDR) Digital WDR
Image Enhancement BLC, HLC, 3D DNR
Privacy Mask 4 rectangular privacy masks
Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
Built-in Microphone 1 built-in microphone
On-board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Speaker 1 built-in speaker
Reset Yes
Basic Event Motion detection (support alarm triggering by specified target type (human)), exception
Power 12 VDC ± 25%, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 10.5 W
Dimension Camera dimension: 163.9 mm × 185.8 mm × 131.9 mm (6.45" × 7.31" × 5.19"), With package dimension: 224 mm × 164 mm × 230 mm (8.82" × 6.46" × 9.06")
Weight Camera weight: 620 g (1.37 lb.), With package weight: 1000 g (2.20 lb.)
Material Plastic
Operating Condition -10 °C to 40 °C (-14 °F to 104 °F). Humidity 90% or less (non-condensing)
General Function Mirror, password protection, watermark
EMC CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014)
Safety CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017)
Environment CE-RoHS (2011/65/EU),Reach (Regulation (EC) No 1907/2006)
Protection IP66 (IEC 60529-2013)

Dokümanlar

Network Camera-V5.8.1_260326 Release Note - 6 MP Fixed Outdoor Smart Hybrid-light PT Network Camera
