Hikvision DS-2TD2608-2/QA - Bullet IP kamera

Markaya göre filtrele

Hikvision DS-2TD2608-2/QA - Bullet IP kamera
Hikvision

Hikvision DS-2TD2608-2/QA - Bullet IP kamera

Model kodu
DS-2TD2608-2/QA
Sistem
Kamera sistemi
Kategori
Bullet IP kamera

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

96 × 72 resolution, 12 μm, VOx UFPA, NETD < 55 mK (25°C, F1.0). Video content analysis: vehicle/human classification. Image processing technology: linear, histogram, self-adaptive thermal AGC mode, DDE, 3D DNR. High quality detector with 10 years guarantee

Teknik özellikler

Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
Resolution 96 × 72
Pixel Pitch 12 μm
Spectral Range 8 μm to 14 μm
NETD < 55 mK (25°C, F1.0)
Focal Length 2.6 mm
IFOV 4.62 mrad
Field of View 25.0° × 18.75° (H × V)
Min. Focusing Distance 0.05 m
Aperture F1.0
Digital Zoom ×2, ×4
Image Sensor 1/1.8" Progressive Scan CMOS
Resolution 2688 × 1520
Min. Illumination 0.0005 Lux @（F1.0，AGC ON）, 0 Lux with Light
Shutter Speed 1 s to 1/100,000 s
Focal Length 6 mm
Field of View 56.0° × 30° (H × V)
Aperture (Range) F1.0
WDR 120 dB
Target Coloration Yes. Supported in white hot and black hot mode.
Light Supplement Warm Light
Light Supplement Distance 30 m
White Light Range Up to 30 m
Visual Alarm Yes. White light alarm with adjustable flashing frequencies
Audio alarm Yes 1 preset voice alerts 6 importable user-defined voice alerts
VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
Main Stream Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288，320 × 240) Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream Thermal: 25 fps (704 × 576, 352 × 288, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240)
Video Compression Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG
Audio Compression G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Protocols IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP,SSL
Network Storage MicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
Simultaneous Live View Up to 20 channels
User/Host level Up to 32 users, 3 levels: Administrator, Operator, User
Security User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Client iVMS-4200, Hik-Connect
Web Browser Live view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +,macOS10.13 +,Safari 12+ Local service : Chrome 57.0 +, Firefox 52.0 +
Alarm Input 2, alarm input (0-5 VDC)
Alarm Output 2, alarm output (alarm response actions configurable)
Alarm Action Linkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
Communication Interface 1, RJ45 10 M/100 M Self-adaptive Ethernet interface.
Web Client Language 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Power Supply 12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3)
Power Consumption 12 VDC ± 25%: 0.7 A, Max.8.5 W PoE (802.3af, class 3): 36 V to 57 V, 0.24 A to 0.15 A, Max. 8.5 W
Working Temperature/Humidity Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less
Protection Level IP67 Standard TVS 4000V lightning protection, surge protection, voltage transient protection IK10-rated housing
Dimensions 211.5 mm × 105 mm × 105 mm (8.32" × 4.13" × 4.13")
Weight 869.2 g (1.92 lb)
VCA Range for Humans 20 m
VCA Range for Vehicles 60 m

Dokümanlar

Data Sheet - Thermal & Optical Bi-spectrum Network Bullet Camera Quick Start Guide - Thermal & Optical Bi-spectrum Network Bullet Camera User Manual - Thermal & Optical Bi-spectrum Network Bullet Camera General Firmware Update Release notes - Thermal & Optical Bi-spectrum Network Bullet Camera
