Hikvision DS-2XC6243G0-L(R)(D/Y) - Bullet IP kamera

Markaya göre filtrele

Hikvision DS-2XC6243G0-L(R)(D/Y) - Bullet IP kamera
Hikvision

Hikvision DS-2XC6243G0-L(R)(D/Y) - Bullet IP kamera

Model kodu
DS-2XC6243G0-L(R)(D/Y)
Sistem
Kamera sistemi
Kategori
Bullet IP kamera

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Anti-corrosion polymer enclosure, protecting cameras to be used in corrosive environments, providing reliability and longevity compared to standard cameras. Water and dust resistant (IP68): the camera can be used under water up to 10 meters. H.265+/H.265/H.264+/H.264 encoding: efficient compression technology saves storage space and reduces bandwidth requirements. Wiper models (-R models) support wiper decontamination. White light supplement, support full color picture. Both -D and -Y models have dissolved oxygen sensors to measure dissolved oxygen concentration and air saturation inside water; D for fresh water sensor; Y for salt water sensor.

Teknik özellikler

Image Sensor 1/3.0" Progressive Scan CMOS
Max. Resolution 2560 × 1440
Min. Illumination Color: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with light
Shutter Time 1/3 s to 1/100,000 s
Lens Type Fixed focal lens, 2.8, and 4 mm optional
Focal Length & FOV 2.8 mm, horizontal FOV 99.5°, vertical FOV 55.5°, diagonal FOV 116.1° 4 mm, horizontal FOV 76.8°, vertical FOV 41.5°, diagonal FOV 90.8°
Aperture F2.0
Supplement Light Type White Light
Supplement Light Range NTU: 0 to 5, up to 1 m, NTU: 5 to 15, up to 0.5 m, NTU: >15, up to 0.2 m
Main Stream 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 8 Mbps
H.264 Type Baseline Profile,Main Profile,High Profile
H.265 Type Main Profile
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region of Interest (ROI) 1 fixed region for main stream
Target Cropping Yes
Protocols SSL/TLS, RTSP, TCP/IP, RTP, HTTP, QoS, PPPoE, ICMP, DDNS, UDP, UPnP, IGMP, DHCP, DNS, SNMP, IPv4, IPv6, FTP, HTTPS, 802.1X, NTP
Simultaneous Live View Up to 6 channels
API ONVIF (Profile S, Profile G),ISAPI,SDK,ISUP
User/Host Up to 32 users 3 user levels: administrator, operator, and user
Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), WSSE and digest authentication for ONVIF,basic and digest authentication for HTTP/HTTPSF, RTP/RTSP over HTTPS, security audit log, control timeout settings
Client iVMS-4200, Hik-Connect, Hik-Central
Web Browser Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Image Settings Rotate mode,saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser
Day/Night Switch Day,Night,Auto,Schedule
Wide Dynamic Range (WDR) 120 dB
Image Enhancement BLC,HLC,3D DNR
Privacy Mask Yes
Picture Overlay LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage Built-in eMMC storage, 64 GB
Reset Key Yes
Basic Event Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection,scene change detection,defocus detection
Linkage Upload to FTP, notify surveillance center, send email, trigger recording, trigger capture
Power 12 VDC, 0.88 A, max. 10.6 W, two-core terminal terminal block, PoE: IEEE 802.3af, Class 3, max. 12.95 W
Material -LY/LD/LRY/LRD: PTS+50%GF + stainless steel -L/LR: PTS+50%GF
Dimension -L: 114 mm × 100.9 mm × 114.9 mm (4.49" × 3.97" × 4.52"), -LR: 122.1 mm × 122.7 mm × 206.6 mm (4.81" × 4.83" × 8.13"), -LD/LY: 192 mm × 169.1 mm × 172 mm (7.56" × 6.66" × 6.77"), -LRD/LRY: 196 mm × 185.4 mm × 264 mm (7.72" × 7.30" × 10.39")
Package Dimension 498 mm × 342 mm × 182 mm (19.60'' × 13.46'' × 7.17'')
Weight -L: approx. 1825 g (4.02 lb.) -LR: approx. 2040 g (4.50 lb.) -LRD: approx. 2845 g (6.27 lb.) -LRY: approx. 2490 g (5.49 lb.) -LY: approx. 1760 g (3.88 lb.) -LD: approx. 1765 g (3.89 lb.)
With Package Weight -L: approx. 2825 g (6.23 lb.) -LR: approx. 3540 g (7.80 lb.) -LRD: approx. 4020 g (8.86 lb.) -LRY: approx. 4038 g (8.90 lb.) -LY: approx. 3345 g (7.37 lb.) -LD: approx. 3300 g (7.28 lb.)
Storage Conditions -10 °C to 50 °C (14 °F to 122 °F)
Startup and Operating Conditions -10 °C to 50 °C (14 °F to 122 °F)
Language 9 languages: English, Italian, French, Portuguese, Spanish, Russian, Japanese, Korean, Thai
General Function Heartbeat, mirror, flash log, password reset via e-mail, pixel counter, anti-banding
Wiper -R: Yes
Cable Length 10 m (32.81 ft.) (included)
EMC CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety CB: IEC 62368-1: 2014, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
Environment CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection IP68: IEC 60529-2013
Anti-Corrosion Protection NEMA 4X (NEMA 250-2018),C5
Measurement Range -LD/-LY/-LRD/-LRY: Dissolved oxygen: 0 to 20 mg/L, 0 to 200% saturation, Temperature: 0 °C to 50 °C (32 °F to 122 °F)
Accuracy -LD/-LY/-LRD/-LRY: Dissolved oxygen: ±0.3 mg/L or ±3%, Temperature: ±0.4 °C (±32.72 °F)
Resolution -LD/-LY/-LRD/-LRY: 0.01 mg/L

Dokümanlar

Data Sheet - Polymer 4MP Underwater Fixed Bullet User Manual - Polymer 4MP Underwater Fixed Bullet E8_IPCH V5.7.8_260713 Release Note - Polymer 4MP Underwater Fixed Bullet
