Hikvision DS-3WF5000-SI-5ACG/2P

Markaya göre filtrele

Hikvision DS-3WF5000-SI-5ACG/2P
Hikvision

Hikvision DS-3WF5000-SI-5ACG/2P

Model kodu
DS-3WF5000-SI-5ACG/2P
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Up to 5 km wireless transmission distance. 867 Mbps 802.11ac wireless bridge. Built-in 16 dBi 2 x 2 MIMO antenna. Visualized topology management. Standard PoE Input & Output. Plug and Play. Easy adjustment with universal joint bracket

Teknik özellikler

Product Dimensions (W × H × D) 134.21 mm × 235.00 mm × 58.73 mm (5.28'' × 9.25'' × 2.31'')
Package Dimensions (W × H × D) 341 mm × 360 mm × 100 mm (13.43" × 14.17" × 3.94")
Net Weight 0.54 kg (1.19 lb) per device
Gross Weight 2.76 kg (6.08 lb)
Packing List Wireless Bridge x 2, PoE Adapter (48.0V, 1.0A) x 2, Power Cord x 2, Universal Joint Nut x 2, Universal Joint x 2, Mounting Bracket x 2, Screw Pack x 2, Hose Clamp x 2, Quick Start Guide x 1, Regulatory Compliance and Safety Information x 1
Packing Method Packing in pairs
Working Temperature -30 °C to 65 °C (-22 °F to 149 °F)
Working Humidity 5% to 95% (no condensation)
Storage Temperature -40 °C to 80 °C (-40 °F to 176 °F)
Storage Humidity 5% to 95% (no condensation)
Installation Mode Wall Mounting,Pole Mounting
Ingress Protection IP55
Power Consumption 3.5 W for typical (1-ch 2MP IPC), Max. 7.7 W
Max. Transmission Rate of Air Interface ≤ 867 Mbps
Wireless Standard IEEE 802.11/a/n/ac
Working Frequency Band 5150 MHz ~ 5250 MHz,5250 MHz~ 5350 MHz,5470 MHz~ 5725 MHz,5725 MHz~ 5825 MHz
Antenna Gain 16 dBi
Antenna Angle (H) Beamwidth [3 dB] 32° (V), Beamwidth [3 dB] 17°
Transmitting Power 29 dBm @11ac 80MHz MCS0 (Note: Transmitting power may vary with local regulations.)
Receiving Sensitivity -88 ±2dBm@AC80-MCS0
Throughput Rate PTP:290 Mbps/1 KM(AC80), 270 Mbps/3 KM(AC80), 250 Mbps/5 KM(AC80); PTMP(1 to 8): 150 Mbps/5KM(AC80)
Network Interface 3 × 100/1000 Mbps RJ45 ports
LED Indicator Power indicator,LAN indicator,Signal intensity indicator
Reset Hardware resetting button
Power Supply 48V PoE/12~24V DC;Check the physical interface image below for more details.
Application Function IFM,IPM,DFS,TPC
Channel Width 20/40/80 MHz
Channel Selection Auto/manual selection
Security Mode WPA2-PSK
Security Mechanism Wireless network name hidden
Network Protocol NTP (network time synchronization),SADP (auto search for IP address), HTTPS/HTTP (web management),SSH (debugging)
Management Method HCP,Web,iVMS-4200,HPP
System Log Syslog,Control center information
Upgrade Web,iVMS-4200,HCP,HPP
HPP Support one-click activation and remote management via Hik-Partner Pro. Functions supported: 1. Reboot device 2. Restore device 3. Display the topology information 4. Display the connection status between AP and CPEs, including signal intensity, background noise, sending & receiving rate. 5. Configure wireless settings, including working mode, SSID, password, channel, channel bandwidth, transmitting power 6. Bridge alignment 7. Spectrum scanning 8. PoE output management
PoE Port AP: LAN1 802.3af/at PoE IN; CPE: LAN1 passive PoE IN, LAN2 802.3 af PoE OUT, LAN3 802.3 af PoE OUT
Max. Port Power 28 W
PoE Power Budget 40 W
PoE Distance 100 m
EMC CE-EMC(EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130-4, EN 55035)
Safety CB (IEC 62368-1),CE-LVD (EN 62368-1)
Chemistry CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
Radio EN 301 893,EN 300 440,EN 301 489-3,EN 301 489-17,EN 301 489-1, EN 61000-3-3, EN IEC 61000-3-2, EN IEC 62311

Dokümanlar

Data Sheet - 5Ghz 867Mbps 5KM Wireless Bridge Kit Quick Start Guide - 5Ghz 867Mbps 5KM Wireless Bridge Kit FAQ - 5Ghz 867Mbps 5KM Wireless Bridge Kit
