Hikvision DS-7708NXI-K4(E) - NVR kayıt cihazı

Markaya göre filtrele

Hikvision DS-7708NXI-K4(E) - NVR kayıt cihazı
Hikvision

Hikvision DS-7708NXI-K4(E) - NVR kayıt cihazı

Model kodu
DS-7708NXI-K4(E)
Sistem
Kamera sistemi
Kategori
NVR kayıt cihazı

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Automatic speed control fans are designed for running quietly and energy saving. Adopt Hikvision AcuSense technology to minimize manual effort and security costs. Efficient playback with AcuSearch technology. Accurate perimeter protection effectively reduces false alarms. Automatic cameras connection and configuration. Up to 8-ch IP camera inputs. H.265+/H.265/H.264+/H.264 video formats. Up to 3-ch@12 MP or 5-ch@8 MP or 8-ch@4 MP or 8-ch@2 MP decoding capacity. Up to 80 Mbps incoming bandwidth

Teknik özellikler

AI by NVR Facial recognition, perimeter protection, motion detection 2.0, AcuSearch
AI by Camera Facial recognition, perimeter protection, motion detection2.0, ANPR
By Camera All channels *: The camera should enable AcuSearch function
By NVR Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarm. Up to 4 MP: 2-ch; 8 MP to 5 MP: 1-ch
By Camera All channels
Facial Detection and Analytics Face picture comparison, human face capture, face picture search
Facial Detection and Analytics Performance Up to 4 MP: 2-ch; 8 MP to 5 MP: 1-ch
Face Picture Comparison 8-ch
Face Picture Library Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 1 MB, total capacity ≤ 1 GB)
By NVR All channels, up to 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
By Camera All channels
IP Video Input 8-ch
IP Speaker Input 4-ch
Incoming Bandwidth 80 Mbps
Outgoing Bandwidth 160 Mbps
HDMI Output 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output 1-ch, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output Mode HDMI/VGA independent output
Audio Output 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input )
Decoding Format H.265, H.265+, H.264, H264+
Recording Resolution 16 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF *: 16 MP is only available for channel 1.
Synchronous Playback 8-ch
Decoding Capability AI on: 2-channel 12 MP@30 fps, 4-channel 8 MP@30 fps, 5-channel 6 MP@30 fps, 8-channel 4 MP@30 fps, 8-channel 3 MP@30fps, 8-channel 2 MP@30fps AI off: 3-channel 12 MP@30 fps, 5-channel 8 MP@30 fps, 6-channel 6 MP@30 fps, 8-channel 4 MP@30 fps, 8-channel 3 MP@30fps, 8-channel 2 MP@30fps
Stream Type Video, Video and Audio
Audio Compression G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2
Remote Connection 128
API ONVIF (profile S/G); SDK; ISAPI
Compatible Browser IE 11, Chrome 91, Firefox 88, Safari 12, Edge 91,or above version
Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
SATA 4 SATA interfaces
Capacity Up to 16 TB capacity for each HDD
Serial Interface 2 RS-485 (half-duplex), 1 RS-232
Alarm In/Out 16/9;16/4
eSATA 1 eSATA interface;NA
USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Ctrl 12V Support;NA
DC 12V Support
GUI Language English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Hebrew, Ukrainian, Indonesian
Fan Supports
Power Supply 100 to 240 VAC, 50 to 60Hz
Consumption ≤ 50 W (without HDD)
Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity 10 to 90 %
Dimension (W × D × H) 440 × 391 × 72 mm (17.32 × 15.39 × 2.82 inch)
Weight ≤ 4kg (without HDD, 9 lb.)
CE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 55035: 2017
Obtained Certification CE,CB,REACH,WEEE,UKCA,RCM,IC

Dokümanlar

Data Sheet - 8-ch 1.5U K Series AcuSense 4K NVR Quick Start Guide - 8-ch 1.5U K Series AcuSense 4K NVR NVR V4.85.040_260725 ReleaseNote - 8-ch 1.5U K Series AcuSense 4K NVR
