Hikvision DS-8108LHFHI-K2 - DVR kayıt cihazı

Markaya göre filtrele

Hikvision DS-8108LHFHI-K2 - DVR kayıt cihazı
Hikvision

Hikvision DS-8108LHFHI-K2 - DVR kayıt cihazı

Model kodu
DS-8108LHFHI-K2
Sistem
Kamera sistemi
Kategori
DVR kayıt cihazı

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Three live view control views are provided: movie mode, picture-in-picture mode, and multi-screen mode. Auto live view control realizes automatic switch of teacher image, student image, and multimedia image, which helps to meet the demand of daily teaching requirement. ACC format audio encoding technology, up to 48 KHz audio input sampling rate, and internal sound mixing feature provide high audio quality. Synchronously collect the teacher image, student image, and multimedia image via HDMI/VGA input. Real-time encoding for all cameras with up to 1080p resolution. Support setting different resolution, frame rate, and bitrate for three streams, including main stream, sub-stream, and third stream. Support searching, playback, and downloading courses by keywords. Support publishing courses to FTP server by pressing the publish button on front panel. Support manual live view control, RTMP live view, playback course, and configure course plan in remote client or platform. Support RTMP multimedia.

Teknik özellikler

IP Video Input 5-ch ; Up to 2 MP resolution; Support H.265/H.264 IP cameras
Analog Video Input 8-ch; BNC interface ; 1080p/25 fps, 1080p/30 fps, 720p/25 fps, 720p/30 fps, 720p/50 fps, 720p/60 fps; Connectable to CVBS signal
HDMI Output 1-ch; 1024 × 768/60 Hz, 1280 × 720/60 Hz, 1280 × 1024/60 Hz, 1920 × 1080/60 Hz
VGA Output 1-ch; 1024 × 768/60 Hz, 1280 × 720/60 Hz, 1280 × 1024/60 Hz, 1920 × 1080/60 Hz
HDMI Input 2-ch; 1024 × 768, 1280 × 720, 1366 × 768, 1680 × 1050, 1920 × 1080; HDMI and VGA can’t be recognised synchronously in same group
VGA Input 2-ch;1024 × 768, 1280 × 720, 1366 × 768, 1680 × 1050, 1920 × 1080; HDMI and VGA can’t be recognised synchronously in same group
HDMI Loopback 1-ch (matching HDMI video in 1)
VGA Loopback 1-ch (matching VGA video in 1)
Audio Output 1-ch dual track of 3.5 mm connector 1-ch dual track of RCA connector 2-ch single track of green connector. Linear Level; Impedance: 1 KΩ
Audio Input 1-ch dual track of 3.5 mm connector 1-ch dual track of RCA connector. Sampling rate: 48 KHz 6-ch single track of green connector. Sampling rate: 48 KHz
Audio Sampling Rate 48 KHz
Video Compression H.265/H.264
Encoding Resolution High-definition stream: 1080p/720p/WD1/4CIF/VGA/CIF Standard-definition stream: WD1/4CIF/CIF Fluent stream: CIF/QVGA
Frame Rate 1 to 25 fps (P)/30 fps (N)
Video Bitrate 32 Kbps to 16 Mbps
Stream Type Video&Audio, Video
Audio Compression AAC
Audio Bitrate 128 Kbps
Synchronous playback 1-ch
Dual-stream Support
Network Interface 2, RJ25 10M/100M/1000M Ethernet interface
SATA 2 SATA interfaces
Capacity Up to 8 TB capacity for each disk
Serial Interface 1 RS-485, full duplex
USB Interface Front Panel: 2 × USB 2.0 Rear Panel: 2 × USB 3.0
Alarm In/Out 2/1
Power Supply 12 VDC
Consumption ≤ 40 W(without HDDs)
Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity 10% to 90%
Chassis 1U
Dimension (W × D × H) 440 × 385 × 45 mm (17.3 × 15.2 × 1.8 inch)
Weight ≤ 5.5 Kg (12.1 lb)
FCC Part 15 Subpart B, ANSI C63.4-2014
CE EN50130-4, EN 61000-3-2,EN 61000-3-3,EN 55032

Dokümanlar

Quick Start Guide - 8-ch 1080p H.265 DVS
