Hikvision DS-D4018CW-2FQ

Markaya göre filtrele

Hikvision DS-D4018CW-2FQ
Hikvision

Hikvision DS-D4018CW-2FQ

Model kodu
DS-D4018CW-2FQ
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

The display and control system is wholly self-developed, which is stable, safety and controllable.. Highly integrated and compatible cabinet with simple and lightweight design.. Easy to disassemble lamp board, power supply, and receiving card on the front side with high- precision aluminum die casting cabinet design.. The solders are made of lead-free and non-toxic solder paste materials, which will not cause harm to human body and the environment.. Automatically identify high-brightness and harsh picture details and adjust the brightness of the partial zones with dynamic engine algorithms adopted. The image is soft and comfortable to view and its quality is enhanced when unnecessary power consumption is reduced.. Automatically remove moisture to protect lamp board from water damage when the device is kept in a humid environment or left unused for a long time.. Support multiple ways to adjust screen parameters via remote control, tablet, and platforms.. The packaging adopts recyclable materials, and the whole process of porduction achieves green and low-carbon standards.. Please note: Module and cabinet sturcture should be seperately ordered.

Teknik özellikler

Product Model DS-D4018CW-2FQ
Product Type Small Pixel Pitch Indoor Full-color LED Display
Pixel Configuration SMD Triad LED (with glue)
Pixel Pitch Category P1.8
Pixel Pitch 1.875 mm
Pixel Density 284444 dots/㎡
Modules Component 2 × 2
Dimensions (W × H × D) 600 mm × 337.5 mm × 29.5 mm (23.622" × 13.287" × 1.161")
Resolution 320 × 180
Area 0.2025 ㎡
Weight 3.4 kg (7.5 lb.)
Cabinet Material Aluminium die casting
Maintenance Method Front maintenance for all components
Module Resolution 160 × 90
White Balance Brightness 600cd/㎡
Color Temperature 3000-10000 K adjustable
Viewing Angle 160°(H)/160°(V)
Contrast Ratio 5000:1
Color Uniformity ≤ ± 0.003Cx，Cy
Brightness Uniformity ≥ 97％
Driving Method Constant current driving
Frame Frequency 60 Hz
Refresh Rate Up to 3840 Hz
Grey Level Up to 16 bit
Max. Consumption ≤ 400 W/㎡
Average Consumption ＜ 140 W/㎡
Input Voltage 100~240 VAC ± 10％
Working Temperature 10 °C to 40 °C (14 °F to 104 °F)
Working Humidity 10% RH to60% RH (without condensation)
Storage Temperature -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
Storage Humidity 10% RH to85% RH (without condensation)
Product Dimension (W × H × D) Module: 4-in-1(443X360X52 mm)，20-in-1 (471X378X266 mm)
Packing List Regulatory Compliance and Safety Information × 1 Connecting screws, light beads, driver IC, iron sheets
Gross Weight Module: 4-in-1 (1.744 kg), 20-in-1 (8.72 kg)； Structure: 1-in-1 (2.8 kg)，5-in-1 (14 kg)
Net Weight Module: 4-in-1 (1.224 kg), 20-in-1 (6.120 kg) Structure: 1-in-1 (2.6 kg)，5-in-1 (13 kg)
Modular Bracket standard bracket:DP-D40XXCB22-1X1-Q0.3-NW-Q0.3-HC 1*1;DP-D40XXCB22-2X2-Q0.8-NW-Q0.8-HC 2*2,ultra-thin bracket:DP-D40XXCB22-1X1-Q0.2-NW-Q0.2-ZF
