Ürün açıklaması
Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.
Loading capacity up to 1,300,000 pixels, maximum width: 4096 pixels, maximum height: 4096 pixels. 2x Gigabit Ethernet ports. 1x HDMI1.4 output port, support up to 1080P@60Hz. 1x HDMI1.4 input port, support full-screen scaling in synchronous mode
Teknik özellikler
| Brightness Control | 1-100 Levels |
|---|---|
| Frame Frequency | 30HZ-60HZ |
| Grey Level | 256 |
| Display Color | 1 Billion |
| Processing Depth | 8bit |
| Image Scaling | Support |
| Product Model | DS-D42B02-N |
| Chassis Height | 0.9U |
| Chassis Width | 3.12U |
| Average Consumption | ≤18W |
| Number of power interfaces | 1 |
| Power interface specifications | 100-240V~，50/60Hz，0.6A |
| Working Temperature | -20℃～+60℃ |
| Storage Humidity | 0%RH～80%RH |
| Working Humidity | 0%RH～80%RH |
| Storage Temperature | -40℃～+80℃ |
| Packaging Size (W × H × D) | 385.0mm×280.0mm×75.0mm |
| Net Weight | 1234g |
| Gross Weight | 1653.6g |
| Dimensions (W × H × D) | 274.3mm×139.0mm×40.0mm |
| Packing List | "1x Wi-Fi omnidirectional antenna 1x AC power cord 1x Quick Start Guide 1x Packing list" |
| Product Type | LED Controller |
| Audio Input Interface(s) | 1 |
| Audio Input Interface Type | HDMI INLINE |
| Video Input Interface(s) | 1 |
| Video Input Interface Type | HDMI1.4 |
| Max. Input Resolution | 1080p@60hz |
| Video Input Resolution | 1080p@60hz |
| Video Input Processing Characteristics | Processing depth 8 BIT Sampling format: RGB:444 YUV:444 YUV:422" |
| Max. Output Resolution | 1.3 Million |
| Loading Capacity for Video Output to LED | Single port with load 650000 Width 64~4096 Height 64~4096 |
| LED Loading Interfaces | 2 |
| LED Loading Interface Type | RJ45 |
| Number of video ring pass output interfaces | 1 |
| Video looping output interface type | HDMI1.4 |
| Video looping output resolution | 1080p@60hz |
| Audio Output Interface(s) | 1 |
| Audio Output Interface Type | 1 LINE OUT 3.5mm audio out |
| Screen | NA |
| Key | SWITCH |
| pilot lamp | PWR:RED, Staying on-The power supply is working properly SYS:GREEN, Flashing once every 2s-The operating system is functioning normally Staying on/off-The operating system is malfunctioning CLOUD:GREEN Staying on-The DS-D42B02-N is connected to the Internet and the connection is available Flashing once every 2s-The DS-D42B02-N is connected to VNNOX and the connection is available Flashing once every second-The DS-D42B02-N is upgrading the operating system Flashing once every 0.5s-The DS-D42B02-N is copying the upgrade package. RUN:GREEN Flashing once every second-The FPGA has no video source Flashing once every 0.5s-The FPGA is functioning normally Staying on/off-The FPGA loading is abnormal" |
| Control network port | 2 RJ45, 10M/100M/1000M adaptive Ethernet ports Used to connect to external networks, can support multi-device network cascade management |
| 3D interface | NA |
| IR input | NA |
| Serial Interface | 1XGigabit Ethernet port |
| Light perception | 2XSENSOR |
| USB | 1XUSB 3.0 |
| On-off | Switch |
