Hikvision DS-D42C20-H

Markaya göre filtrele

Hikvision DS-D42C20-H
Hikvision

Hikvision DS-D42C20-H

Model kodu
DS-D42C20-H
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

20-ch gigabit Ethernet output ports, up to 4096 × 2160@60 Hz signal source access. 1-ch HDMI 2.0 output, and 1-ch HDMI 1.4 live view output.. 2-ch HDMI 2.0 input interfaces: Supports 4096 × 2160@60 Hz, up to 7680 × 1080@60 Hz.. Automatic signal source search: Enables automatic signal source search by default.. 3D synchronized signal input and output interface: The sending card can process 3D signals, and the single card supports 3840 × 1080p@120 Hz input and output.. Audio device access: The sending card, with audio input and output interfaces, supports audio device access.. Light sensor expansion: The sending card has a light sensor expansion interface, and the light sensor adjustment function can be enabled without adding a multi-functional card.. Dual-mode remote control expansion interfaces: Equipped with infrared and USB RF Wi-Fi expansion interfaces. The dual-mode supports remote control.. Large load capability: 10 MP.. Cloud upgrade: The system program supports remote upgrade on cloud.. Supports remote control, with the screen displaying remote control UI menu.. Scene management: You can customize and switch scenes out of various options.. Multi-controller auto splicing and cascade display for synchronization.. High refresh rate of 3840 Hz, nanosecond response time, and smooth video images.

Teknik özellikler

Brightness Control 1-100 Levels
Frame Frequency 25HZ-120HZ
Grey Level 1024
Display Color 1 Billion
Processing Depth 10bit
Image Scaling Support
Product Model DS-D42C20-H
Chassis Height 1.5 U
Chassis Width Full Width
Average Consumption ≤38W
Number of power interfaces 1
Power interface specifications 100～240 VAC, 50/60 Hz
Working Temperature 0°C ~ 50°C
Storage Humidity 10% ～ 90%
Working Humidity 10% ～ 90%
Storage Temperature -10°C ~ 50°C
Packaging Size (W × H × D) 576mm × 428 mm × 121 mm
Net Weight 2.4KG
Gross Weight 4.13KG
Dimensions (W × H × D) 442 mm × 249.5 mm × 53mm
Packing List AC power cord*1, 1U chassis accessory kit*1, Manual*1, Foot pad assembly*1
Product Type LED Controller
Audio Input Interface(s) 3
Audio Input Interface Type 2 HDMI inline + 1 line-in
Video Input Interface(s) 2
Video Input Interface Type 2 HDMI2.0 (optional)
Max. Input Resolution 4K
Video Input Resolution HDMI2.0 interface Maximum supported resolution: 4096*2160@60Hz Minimum supported resolution: 320*180@60Hz Customizable resolution, total resolution not more than 8.85 Million@60 Limit width: 320~8192 Alignment: 4 alignment Limit height: 180~8192 Alignment: 1 alignment Support HDCP1.4 Does not support interlaced signal input
Video Input Processing Characteristics Processing depth 8/10bit Sampling format: RGB:444 YUV:444 YUV:422
Max. Output Resolution 13 Million
Loading Capacity for Video Output to LED Single mesh port with load 65W Width 480~7680;Alignment: 2 Alignment Height 270~4320;Alignment: 1 alignment
LED Loading Interfaces 20
LED Loading Interface Type RJ45
Number of video ring pass output interfaces 1
Video looping output interface type HDMI 2.0
Video looping output resolution 4096*2160@60Hz
Audio Output Interface(s) 2
Audio Output Interface Type 1 HDMI loop out +1 LINE OUT 3.5mm audio out
Screen Digital Tube
Key ""+"": brightness increase "-": brightness decrease "Source": switch the signal source"
pilot lamp PWR: Power indicator STAT:Status indicator ASYNC: Internal Android source status light SYNC: External source status light
Control network port 2 RJ45, 10M/100M/1000M adaptive Ethernet ports Used to connect to external networks, can support multi-device network cascade management
3D interface 1 SYNC for 3D signal configuration, 3-Core S-terminal
IR input 1 x 3.5mm cradle Support infrared remote control access
Serial Interface 1, 1 debug serial port (RJ45)
Light perception 1 light-sensitive aviation head
USB 2 x USB 2.0
On-off Switch

Dokümanlar

Data Sheet - LED Control Card
