Hikvision DS-D42V24-H

Markaya göre filtrele

Hikvision DS-D42V24-H
Hikvision

Hikvision DS-D42V24-H

Model kodu
DS-D42V24-H
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Multiple Signal Interfaces: 6 channels of video signal input (2 × HDMI 2.0 and 4 × DVI), 6 channels of video signal output (2 × HDMI 2.0 and 4 × DVI); 1 channel of HDMI 1.4 output for pre-monitoring; 1 channel of 3D signal synchronization output for 3D display.. Ultra-Large Load Capacity: 24 channels of network interface with the resolution of up to 15.60 MP.. HDR Output: Provides more lively and colorful image with high quality and clear details.. Multi-Windows Display: Free layout of 9 windows with 6 signal input windows and 3 picture/text windows; free switching, cutting, stitching, and zooming in/out.. Output Signal Pre-Monitoring: Sends the output signal to your monitor through the HDMI interface.. Self-Stitching Display: Larger scale stitching display achievable through self-stitching of multiple controllers (a cascade of up to 4 controllers allowed), ensuring the synchronization within different controllers.. Scenes Configurable: Up to 10 scenes can be configured and saved as templates for convenience.. EDID Settings Customizable: HDCP 2.2 protocol for high-bandwidth digital content protection.

Teknik özellikler

Product Type LED Display Controller
Video & Audio Input 2 × HDMI interface, Max. resolution: 4096 × 2160@60 Hz 4 × DVI interface, Max. resolution: 1920 × 1200@60 Hz
Video & Audio Output 1 × HDMI interface for pre-monitoring, Max. resolution: 1920 × 1080@60 Hz 2 × HDMI interface, Max. resolution: 4096 × 2160@60 Hz 4 × DVI interface, Max. resolution: 1920 × 1200@60 Hz 24 × network interface
Control Interface 1 × RJ45 10/100/1000 MB self-adaptive
Max. Load Capacity 15.60 MP
Brightness Control 1 to 100 levels adjustable (gradual white balance)
Frame Frequency 60 Hz
Grey Level 16 bit
Max. Resolution of Bar Display 5000 × 256 pixels
Display Color 2^16× 2^16 × 2^16
Processing Depth 8 bit, 10 bit
Max. Consumption 60 W
Average Consumption 45 W
Input Voltage 100 to 240 VAC
Working Temperature 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
Working Humidity 10% to 80%
Storage Temperature -10 ℃ to 60 ℃ (14 ℉ to 140 ℉)
Storage Humidity 10% to 80%
Product Dimensions (W × H × D) 442 mm × 309.5 mm × 88 mm (17.40'' × 13.33'' × 3.62'')
Package Dimensions (W × H × D) 572 mm × 396 mm × 163 mm (22.52'' × 15.59'' × 6.42'')
Net Weight 5.25 kg (11.57 lb.)
Gross Weight 7.25 kg (15.98 lb.)

Dokümanlar

Quick Start Guide - LED Control Card
