Hikvision DS-E04HGHI-XD - DVR kayıt cihazı

Markaya göre filtrele

Hikvision DS-E04HGHI-XD - DVR kayıt cihazı
Hikvision

Hikvision DS-E04HGHI-XD - DVR kayıt cihazı

Model kodu
DS-E04HGHI-XD
Sistem
Kamera sistemi
Kategori
DVR kayıt cihazı

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Powered by M-SATA eSSD technology. Deep learning based human and vehicle targets classification of Motion Detection 2.0. Scene-adaptive bitrate control video compression. Up to 1080p Lite@30 fps encoding capability. Low power consumption. Audio via coaxial cable

Teknik özellikler

Human/Vehicle Analysis Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
IP Video Input 1-ch Up to 1080p resolution Support H.265+/H.265 IP cameras
Analog Video Input 4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input 1080p25, 1080p30, 720p25, 720p30
AHD Input 1080p25, 1080p30, 720p25, 720p30
HDCVI Input 1080p25, 1080p30, 720p25, 720p30
CVBS Input Support
HDMI Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode HDMI/VGA simultaneous output
Audio Input 4-ch via coaxial cable
Audio Output 1-ch via HDMI
Synchronous playback 4-ch
Video Compression H.265 Pro/H.265
Encoding Resolution 1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA
Frame Rate Main stream: 1080p Lite/720p/720p Lite/WD1/4CIF@25 fps (P)/30 fps (N) Note: 1080p Lite/720p is 15 fps by default Sub-stream: 4CIF@15 fps; CIF/QVGA@25 fps (P)/30 fps (N)
Video Bitrate According to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.
Stream Type Video, Video & Audio Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.
Audio Compression G.711u
Audio Bitrate 64 Kbps
Total Bandwidth 64 Mbps Incoming bandwidth: 4 Mbps
Remote Connection 32
Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
Network Interface 1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Capacity Built-in 512 GB eSSD (480 GB available) Note: M-SATA interface, capable of plugging and upgrading capacity. The device can store about 4 weeks videos for 4-ch analog cameras (default parameters), this estimation is for reference only.
USB Interface Rear panel: 2 × USB 2.0
Alarm In/Out N/A
Power Supply 12 VDC, 1 A
Consumption ≤ 5.4 W (with eSSD)
Working Temperature -10 °C to 45 °C (14 °F to +113 °F)
Working Humidity 10% to 90%
Dimension (W × D × H) 152 × 113 × 46 mm(6.0 × 4.4 × 1.8 inch)
Weight ≤ 0.5 kg (with eSSD, 1.1 lb.)

Dokümanlar

Turbo HD DVR V4.75.030 build250508 Release Notes - 4-ch 1080p Lite 1U H.265 eSSD DVR
