Hikvision DS-KAS541
Hikvision

Hikvision DS-KAS541

Model kodu
DS-KAS541
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Touch-free single-door access control solution. Deep learning face recognition. 2 mega pixel dual-lens camera. 4.3-inch LCD touch screen. Access control with multiple authentication modes. IP65

Teknik özellikler

Model DS-K1T341CMF
Operating system Linux
Screen size 4.3-inch
Operation method Capacitive touch screen
Type LCD
Resolution 480 × 800
Lens × 2
Resolution 2 MP
Wired network 10 M/100 M/1000 M self-adaptive
Network interface 1
Lock control 1
Exit button 1
Door contact input 1
TAMPER 1
RS-485 1
Wiegand 1
USB 1
Face capacity 1,500
Fingerprint capacity 1,500
Card capacity 1,500
Event capacity 150,000
Face recognition distance 0.3 to 1.5 m
Face recognition accuracy rate ＞99%
Face recognition duration ＜ 0.2 s
Fingerprint recognition duration ＜ 1 s
Card type M1 card
Card reading frequency 13.56MHz
Card reading distance 0 to 3 cm
Card reading duration ＜ 1 s
QR code recognition Support
Face anti-spoofing Support
Audio prompt Support
Time synchronization Support
Button Touch screen
Power supply 12 VDC, 2 A.
Working temperature -30 °C to 60 °C (-22 °F to 140 °F)
Working humidity 0 to 90% (No condensing)
Protective level IP65
Dimensions 172.5 mm × 83.2 mm × 22.7 mm (6.79" × 3.27" × 0.89")
Installation Surface mounting
Model DS-K4H258S
Unlock method Current interruption
Maximum holding force 280 kg (617.4 Lbs) linear thrust
Power supply 12 VDC, 340 mA
Indicator Green (work status)
Surface temperature ≤ ambient temperature 20 °C (68 °F)
Working temperature -10 °C to 55 °C (14 °F to 131 °F)
Working humidity 0 to 95% (relative humidity)
Dimensions Lock body: 238 mm × 45 mm × 25 mm (9.4" × 1.8" × 1.0") Armature plate: 182 mm × 38 mm × 12.5 mm (7.2" × 1.5" × 0.5")
Weight 2.1 kg (4.6 Lbs)
Suitable door Wooden door, glass door, metal door, fireproof door
Shell performance Hard anodizing electroplating operated
Lock body Eco-friendly Nickel electroplating operated
Armature plate Eco-friendly Nickel electroplating operated
Model FM11RF08-M1
RAM 1 K byte
Card reading frequency 13.56 MHz
Card property Thin card
Function Read/write
Card reading distance ≤10 cm
Working temperature -20 °C to 75 °C (-4 °F to 167 °F)
Dimensions 85.5 mm × 54 mm × 0.8 mm (3.37"× 2.13" × 0.03")
Weight ＜ 5.6 g (0.2 oz)
Material PVC
Color White
Dimensions L-bracket: 238 mm ×30 mm × 47 mm (9.4" × 1.2" × 1.9") Z-bracket: 185 mm ×44mm × 100 mm (7.3" ×1.7" × 3.9")
Model DS-K4H258-LZ
Suitable Door Wooden, metal
Shell performance Hard anodizing electroplated
Weight 0.77 kg (1.7 lb)
Model DS-K7P03
Power supply 12 VDC, 40 mA (standby)/70 mA (working)
Current rating 1 A@30 VDC
Working temperature -20 °C to 50 °C (-4 °F to 122 °F)
Working humidity 0 to 95% (relative humidity)
Dimensions 86 mm × 86 mm × 25.7 mm (3.39" × 3.39" × 1.01")
Weight 0.2 kg (0.44 lb)
Material Stainless steel
Output contact NO/NC/COM contact
Aging test Already passed 1 million times aging test
Suitable door All kinds of narrow doorframes

Dokümanlar

Data Sheet - Face Recognition Terminal Kit
