Hikvision DS-KIS303-P - Hibrit kayıt cihazı

Markaya göre filtrele

Hikvision DS-KIS303-P - Hibrit kayıt cihazı
Hikvision

Hikvision DS-KIS303-P - Hibrit kayıt cihazı

Model kodu
DS-KIS303-P
Sistem
Kamera sistemi
Kategori
Hibrit kayıt cihazı

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Hybrid Intercom Kit with 1 indoor station and 1 four-wire analog door station. User-friendly control with a convenient touch screen. Convenient management via the Hik-Connect mobile client. More cost-effective options with analog doorbells. Easy installation as the doorbell requires no exclusive power supply. Anti-oxidant aluminium alloy with IP65 protection level

Teknik özellikler

Resolution 1920 x 1080
FOV Horizontal: 66.2°，Vertical: 37.2°
Audio input Built-in omnidirectional microphone
Audio output Built-in loudspeaker
I/O output 1 relay output
Four-wire 1 for 4-wire interface
Power supply 12 VDC
Power consumption Max. 5 W
Working temperature -10° C to 55° C (14° F to 131° F)
Working humidity 10% to 90%
Dimensions 135.14 mm × 49.6 mm × 41.93 mm (5.32" × 1.95" × 1.65")
Operation system Embedded Linux operation system
RAM 128 MB
ROM 32 MB
Size 7-inch colorful TFT screen
Operation method Capacitive touch screen
Type Colorful TFT screen
Resolution 1024 × 600
Resolution /
Lens /
WDR /
FOV /
Audio input Built-in omnidirectional microphone
Audio output Built-in loudspeaker
Audio compression Rate 64 Kps
Audio compression standard G.711 U G.711 A
Volume adjustment Adjustable
Audio quality Noise suppression and echo cancellation
Linked IPC capacity 16
Notice capacity 200
Linked indoor extensions capacity 5
Linked doorphone capacity 2 analog doorphones, 15 IP doorphones Max.
Wi-Fi Wi-Fi 802.11 b/g/n
3G/4G /
Bluetooth /
Protocol TCP/IP, SIP, RTSP
Network interface 1 RJ-45 10/100 Mbps self-adaptive
RS-485 1
Alarm input 2-ch alarm inputs
Alarm output 2
Power input 1, 12 VDC
TAMPER /
TF card Max to 128 G, SD 2.0 or lower version
USB interface /
Four-wire interface 2
Button 0
Power supply IEEE802.3af, Standard PoE,12V DC
Power consumption ≤ 6 W
Working temperature -10 °C to 50 °C (14 °F to 122 °F)
Working humidity 10% to 90%
Dimensions (W × H × D) 200 mm × 140 mm × 23.6 mm (7.9" × 5.5" × 0.9")
Installation Surface mounting
Application environment Indoor
Protective level /
Weight With package: 365 g Without package: 355 g

Dokümanlar

Data Sheet - Hybrid Intercom Kit Quick Start Guide - Hybrid Intercom Kit R0 Indoor Station Firmware V2.2.124_build260814 Release Note - Hybrid Intercom Kit
