Hikvision DS-KIS604-P(B)

Markaya göre filtrele

Hikvision DS-KIS604-P(B)
Hikvision

Hikvision DS-KIS604-P(B)

Model kodu
DS-KIS604-P(B)
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Standard PoE. Noise suppression and echo cancellation. Configuration remotely via Web. Stores messages and captured pictures in the TF card. Remote unlocking via the client software or the mobile client

Teknik özellikler

Operation system Embedded Linux operation system
Operation mode Single-button
Flash 32 M
RAM 256 M
Camera 2MP HD camera
Night vision Low illumination IR supplement mode:3 m
Backlight compensation Support
Digital noise reduction Support
WDR True WDR
Field of view Horizontal: 129° Vertical: 75°
Video Compression Standard H.264
Stream Main stream: 1080p@30fps, 720p@25fps Sub stream: D1@25fps
Motion detection Support
Flash-avoid frequency 50 Hz, 60 Hz
Audio input Built-in omnidirectional microphone
Audio output Built-in loudspeaker
Audio quality Noise suppression and echo cancellation
Audio compression standard G.711 U
Audio compression Rate 64 Kbps
Audio intercom Two-way audio communication
Network protocol TCP/IP, RSTP
Wired network 10/100 Mbps Ethernet
RS-485 1
Alarm input 4
Debugging port 1
Grounding 1
TAMPER switch 1
Power consumption ＜ 10 W
Working temperature -40° C to 53° C(-40° F to 127.4° F)
Working humidity 10% to 95%
Dimension 174 mm × 91 mm × 29 mm
Installation Surface mounting/ Flush mounting
Protection level IP65, IK08
Indicator 3
Power supply IEEE802.3af, standard PoE 12 VDC
Operation system Embedded Linux operation system
Memory 128 MB
Flash 32 MB
Display screen 7-inch colorful TFT screen
Display resolution 1024 × 600
Operation method Capacitive touch screen
Audio input Built-in omnidirectional microphone
Audio output Built-in loudspeaker
Audio quality Noise suppression and echo cancellation
Audio compression standard G.711 U
Audio compression Rate 64 Kbps
Wired network 10/100 Mbps self-adaptive
Wireless network Wi-Fi 802.11 b/g/n
Protocol TCP/IP, SIP, RTSP
Network interface 1 RJ-45 10/100 Mbps self-adaptive
RS-485 1
Alarm input 8-ch alarm inputs
Relay output 2
TF card Max to 32 G, SD 2.0 or lower version
Power consumption ≤ 6 W
Working temperature -10 °C to 55 °C (14 °F to 131 °F)
Working humidity 10% to 90%
Dimension (L x W x H) 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")

Dokümanlar

KV(-B) Firmware V2.2.53_220816 Release Note - IP video intercom kit
