Hikvision DS-KIS606-P

Markaya göre filtrele

Hikvision DS-KIS606-P
Hikvision

Hikvision DS-KIS606-P

Model kodu
DS-KIS606-P
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

IP video intercom kit for villa. One-press call button for easier calls. Convenient Hik-Connect APP mobile control. Device included: DS-KV6113-PE1(C) × 1, DS-KH6110-WE1 × 1, DSKABV6113-RS × 1, Administrator card x 1, PSU × 2

Teknik özellikler

Operation system Linux
Processor Embeded high performance processor
RAM 256 MB
ROM 32 MB
Supplement light IR light, up to 3 m
Resolution Main stream: 1920 × 1080p,1280 X 720p Sub stream: 1280 X 720p,640 x 480p
Lens 2MP HD camera
Field of view Horizontal: 131°, Vertical: 78°
Video Compression Standard H.264; H.265; MJPEG
Audio input 1 built-in omnidirectional microphone
Audio output 1 built-in loudspeaker
Audio quality Noise suppression and echo cancellation
Volume adjustment Adjustable
Audio compression standard G711U、G711A、G726、AAC_LC、AAC_LD、OPUS、G722.1
Audio compression Rate 64 Kbps
User capacity 2000
Linked indoor station capacity 16
Card capacity 10000
Network protocol TCP/IP, RTSP, IPV6,ONVIF
Network interface 1 RJ-45, 10/100 Mbps self-adaptive
RS-485 1
Alarm input 4
Lock control 1 relay, Max. 30 VDC 2 A
Exit button 1
Door contact input 1
TAMPER 1
Button 1 physical button(s)
Power consumption ＜ 10 W
Working temperature -40 °C to 55 °C(-40 °F to 131 °F)
Working humidity 10% to 95% (no-condensing)
Dimension 138 mm × 65 mm × 27 mm (5.4" × 2.6" × 1.1")
Installation Surface mounting
Protection level IP65
Indicator 2
Application environment Outdoor
Power supply IEEE802.3af, standard PoE 12 VDC
Weight Net weight: 0.190 kg； Gross weight: 0.414 kg
Operation system Embedded Linux operation system
RAM 128 MB
ROM 16 MB
Processor Embedded processor
Display resolution 480 × 272
Operation method Capacitive touch screen with 9 touch buttons
Screen size 4.3-inch colorful TFT screen
Type Colorful TFT screen
Video compression standard /
Resolution /
Lens /
Wide dynamic range (WDR) /
FOV /
Audio input Built-in omnidirectional microphone
Audio output Built-in loudspeaker
Audio quality Noise suppression and echo cancellation
Audio compression standard G.711 U, G.711 A
Audio compression bitrate 64 Kps
Volume adjustment Adjustable
Notice capacity 200
Linked indoor extensions capacity 16
Network protocol TCP/IP, SIP, RTSP
Wi-Fi Wi-Fi 802.11 b/g/n, 2.4 GHz
Network interface 1 RJ-45 10/100 Mbps self-adaptive
Button 9 physical button
Power consumption ≤ 4 W
Power supply IEEE802.3af, Standard PoE,12 VDC
Working temperature -10 °C to 50 °C (14 °F to 122 °F)
Working humidity 10% to 95% (no-condensing)
Dimension (L x W x H) 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")
Dimension (W × H × D) 120 mm × 120 mm × 21 mm (4.7" × 4.7" × 0.83")
Installation Wall mounting, table mounting
Application environment Indoor
Protective level /
Weight With package: 336.6 g Without package: 197.8 g
Language English, French, Portuguese, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Turkish, Vietnamese, Arabic, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian Danish, Slovenian, Slovak, Swedish, Finnish, Traditional Chinese, Mongolian, Hebrew, Kazakh, Uzbek

Dokümanlar

Data Sheet - IP Video Intercom Kit Quick Start Guide - IP Video Intercom Kit

Bu ürünü satan firmalar

1 firma
TESAN İLETİŞİM A.Ş
Bahçelievler, İstanbul
