Hikvision DS-KIS902-S

Markaya göre filtrele

Hikvision DS-KIS902-S
Hikvision

Hikvision DS-KIS902-S

Model kodu
DS-KIS902-S
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Convenient Hik-Connect APP Mobile Control. Multiple authentication methods: Face, Pin Code, Card, QR Code, Blue tooth. Standard PoE power supply. Stores messages and captured pictures in the TF card. Including: DS-KV9503-WBE1 x 1, DS-KH6350-WTE1 White x 1, 4 ports standard PoE switch x 1, DS-KABV9503-RS x 1, Administrator card x 1, Key fob x 5, PSUx 1

Teknik özellikler

Operation system Embedded Linux operation system
Flash 4 GB
RAM 1 GB
Screen size 4.3-inch
Resolution 800 × 480
Type IPS
Operation method Non-touch screen
Brightness 425 cd/m²
Supplement light IR light, up to 3 m
Resolution Main stream: 1920 × 1080p, 1280 x 720p Sub stream: 1280 x 720p，640 × 480p
Lens 2 × 2 MP
Wide dynamic range (WDR) Support 120 dB
FOV Horizontal: 88°, Vertical: 44°
Video Compression Standard H.264, H.265, MJPEG
Motion detection Support
Audio input 1 built-in omnidirectional microphone
Audio output 1 Built-in loudspeaker
Audio quality Noise suppression and echo cancellation
Volume adjustment Adjustable
Audio compression standard G711U、G711A、G726、AAC_LC、AAC_LD、OPUS、G722.1
Audio compression Rate 64 Kbps
Face capacity 10000
User capacity 20000
Card capacity 100000
Network protocol TCP/IP, RSTP
Wi-Fi IEEE802.11b, IEEE802.11g, IEEE802.11n
Bluetooth Reserved
Card reading frequency 13.56 MHz
Face recognition distance 0.3 to 2 m
Face recognition accuracy rate ≥ 99%
Face recognition duration ＜ 0.2 s per person
Network interface 1 RJ-45, 10/100 Mbps self-adaptive
RS-485 1
Alarm input 4 (2 exit butttons and 2 door contacts by default)
Lock control 2 relays, Max. 30 VDC 2 A
Exit button 1
TAMPER switch 1
Door contact input 1
Button 1 physical button(s)
Power consumption ≤ 6 W
Working temperature -40 °C to 60 °C (-40 °F to 140 °F)
Working humidity 10% to 90% (no-condensing)
Dimension 182 mm × 85 mm × 26 mm (7.16" × 3.34" × 1.01")
Installation Surface mounting
Protection level IP65, IK08
Indicator /
Application environment Outdoor
Power supply IEEE802.3af, standard PoE 12 VDC, 1.5 A
Weight Net weight: 0.405 kg; Gross weight: 0.752 kg
Operation system Embedded Linux operation system
Memory 128 MB
Flash 32 MB
Display screen 7-inch colorful TFT screen
Display resolution 1024 × 600
Operation method Capacitive touch screen
Audio input 1 built-in omnidirectional microphone
Audio output 1 built-in loudspeaker
Audio quality Noise suppression and echo cancellation
Audio compression standard G.711 U, G.711 A
Audio compression Rate 64 Kbps
Volume adjustment Adjustable
Notice capacity 200
Linked indoor extensions capacity 16
Protocol TCP/IP, SIP, RTSP
Wi-Fi 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
Network interface 1 RJ-45 10/100 Mbps self-adaptive
RS-485 1
Alarm input 8-ch alarm inputs
Alarm output 2
TF card Max to 128 G
Power consumption ≤ 5 W
Power supply 12 VDC,IEEE802.3af, Standard PoE
Working temperature -10 °C to 50 °C (14 °F to 122 °F)
Working humidity 10% to 90%
Dimension (L x W x H) 175 mm × 113.5 mm × 21 mm (6.9" × 4.5" × 0.83")
Installation Wall mounting, table mounting
Application environment Indoor
Weight Net weight: 355 g (0.8 lb) Gross weight: 683 g (1.5 lb)

Dokümanlar

B1Pro Indoor Station Firmware V2.2.114_build260618 Release Note - IP Video Intercom Kit
