Hikvision DS-KP6000-HE1
Markaya göre filtrele
ABB
Absen
Ajax
APart Audio
Aruba
Aselsan
AselsanNET
Astor Şarj
ASUS
Atlas Turnike
Bawcon
Biwin
Bosch
Bticino
BULLWARK
CamBox
CAME
Cenova
Commax
Dahua
Dayline
Dayzip
Decon
Dell
DSC Alarm
EATON
Endikal
Eşarj
EZVIZ
FAAC
Fanvil
Finder
Formrack
Fujitron
Gigaset
Global
GVD
Hikvision
HiLook
Hochiki
HP
Imou
Inform
Inter-M
Jabra
Kamera Kutusu
Karel
Lande
Legrand
Leyard
LifeSmart
Mavili
Multitek
Netelsan
NETGEAR
Neutron
Nice
Notifier
Omada
Osram
Özak
Panasonic
Paradox
Philips
Proxsen
QNAP
Rapoo
Reyee
Ruijie
Schneider Electric
Seagate
Suprema
Teknim
Teknosec
Teletek
Tenda
Tescom
Tiandy
TOA
Toshiba
TP-Link
Ttec
Ubiquiti
Unilumin
Uniwiz
UNV
Vestel
vGUARD
Westa
Western Digital
Wisetech
ZES
ZKTeco
ZYXEL
Eşleşen marka yok.
Ürün açıklaması
Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.
2.3-inch 128 × 48 pixel dot-matrix display. 4 SIP Lines; 33 physical keys. Support audio codec G.722 and Opus, HD audio on speakerphone and handset. Dual 10/100 Mbps network ports, integrated PoE. Two installation methods of desktop stand and wall mountable
Teknik özellikler
| Operating system | Embedded Linux operation system |
|---|---|
| ROM | 16 MB |
| RAM | 64 MB |
| Screen size | 2.3-inch |
| Operation method | Physical keys |
| Type | Dot-matrix display screen |
| Resolution | 128x48 |
| Audio compression standard | Narrowband Codec: G.711a/u, G.723.1, G.726, G.729A/B, iLBC Wideband Codec: G.722, Opus |
| Audio input | HD voice microphone; HAC handset |
| Audio output | HD voice speaker (handset/hands-free, 0 ~ 7KHz frequency response) |
| Audio quality | Full-duplex Acoustic Echo Canceller (AEC) / Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR) / Automatic Gain Control (AGC) |
| Volume adjustment | Adjustable |
| Communication Lines | 4 SIP Lines |
| Contact capacity | Local phonebook (1000 entries) Remote phonebook (XML/LDAP, 1000 entries) |
| Call log capacity | In/Out/Missed, 600 entries |
| Communication protocol | SIP2.0 over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 LLDP PPPoE L2TP OpenVPN SNTP FTP/TFTP HTTP/HTTPS TR-069 AES128 & AES256 |
| Wired network | 10/100 Mbps self-adaptive, dual bridged port for PC bypass |
| Wi-Fi standard | / |
| Network interface | 2 RJ-45 10/100 Mbps self-adaptive: Network x1, PC x1 (Bridged to Network) |
| Power supply input | DC power input |
| Communication interface | 2 RJ-9 ：handset x1, headset x1 |
| Button | 33 physical keys, including: 4 Soft-keys; 9 function keys (Hold/Transfer/Voice message/Conference/Phonebook /MWI/Headset/Redial/Hands-free) ; 4 Navigation keys; 1 OK key; 12 Standard Phone Digits keys; 3 Volume Control keys (Up/Down/Mute (Microphone)) |
| Installation | Desktop stand Wall mounting (optional) |
| Indicator | Red: calling and message waiting |
| Working temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Working humidity | 10% to 95% (no-condensing) |
| Dimensions | Desktop Stand (45°): 169x203.6x172.7 mm ; Desktop Stand (50°): 169x194x181 mm ; Wall mountable: 169x113.4x207.6 mm |
| Power supply | IEEE802.3af, Standard PoE,5 VDC, 0.6 A |
| Application environment | Indoor |
| Power consumption | Power Consumption(Adapter): 0.8~1.29W Power Consumption(PoE): 1.25~1.86W |
| Language | English, Simplified Chinese, Traditional Chinese, Russian, Italian, French, German. Hebrew, Spanish, Catalan, Basque, Galician, Turkish, Hungarian, Slovenian, Czech, Korean, Dutch, Ukrainian, Portuguese, Polish |
