Hikvision DS-MCC206

Markaya göre filtrele

Hikvision DS-MCC206
Hikvision

Hikvision DS-MCC206

Model kodu
DS-MCC206
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Light and small. Approx. 50 g (0.1 lb., without back plate) and comfortable to wear.. Supports Wi-Fi connection. Supports live view and control via the application of mobile phone.. Wearable with the magnet or pin.. Data loss prevention function: If the battery is low when recording, the device will automatically save the recorded data before shutting down.. Customizable plate information (with self-adhesive paper).

Teknik özellikler

Image Sensor 1/2.9" progressive scan CMOS
Max. Resolution 1600 × 1200
Focal Length 1.36 mm fixed lens
FOV Horizontal FOV: 91° Vertical FOV: 74° Diagonal FOV: 115°
Aperture F2.2
Video Format PS, MP4
Video Compression H.264, H.265
Main Stream 60 Hz: 30 fps (1600 x 1200, 1280 x 960, 640 × 480)
Audio Compression for Video Recording G722_1,AAC
Audio Bit Rate G722_1(16 kbps) ,AAC(64 kbps)
Image Format JPEG
RAM 128 MB
ROM 32 GB; 64 GB optional
Wi-Fi Frequency Band 2.412 to 2.472 GHz
Wi-Fi Protocol 802.11 a/b/g/n
Protocol HTTPS, RTSP, NTP, FTP
API ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
Audio Type 1 built-in mic(s)
Indicator 2 Indicator(s) for Charging/Working/Recording/Exception/Wifi
Button Power, Wi-Fi
Charging Interface Type-C
USB USB 2.0
Operating System Linux
Client Hik-Connect, HikCentral Pro, HikCentral Master Lite
Power 5 VDC, 2.0 A, max. 10 W
Operating Condition Temperature: -20 °C to +55 °C (-4 °F to +131 °F) Humidity: 90% or less (non-condensing)
Dimension 81 mm × 32.4 mm × 9 mm (3.2" × 1.3" × 0.4")
Weight 50 g (0.1 lb., without back plate)
MIC Supported
Capacity 1550 mAh
Battery Type Lithium-ion battery, integral
Charging Time ≤ 3 h
Battery Duration Up to 12 h in 720p resolution¹
RF EN 300 328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G)
EMC CE-EMC: EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014
Safety CB: IEC 62368-1: 2014+A11, IEC 62368-1: 2018 CE-LVD: EN 62368-1: 2014/A11: 2017, EN IEC 62368-1:2020+A11:2020
Environment CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Warranty 2 years for the device, 1 year for the battery

Dokümanlar

Data Sheet - Economical Nameplate Camera
