Hikvision DS-MCC20D

Markaya göre filtrele

Hikvision DS-MCC20D
Hikvision

Hikvision DS-MCC20D

Model kodu
DS-MCC20D
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Wear with the magnet or pin.. Data loss prevention function: If the battery is low when recording, the device will automatically save the recorded data before shutting down.. Supports Wi-Fi connection. Supports live view and control via the application of mobile phone.. The 4G module is optional.

Teknik özellikler

Image Sensor 1/5" progressive scan CMOS
Max. Recording Resolution 1600 × 1200
Focal Length 1.36 mm fixed lens
FOV Horizontal FOV:94°，Vertical FOV: 74°
Aperture F2.2
Video Compression H.264, H.265
Main Stream 30fps (1600*1200, 1280*960, 640*480)
Sub-Stream NOT Support
Video Format PS, MP4
Audio Compression for Video Recording G722.1
Audio Bit Rate 16 Kbps (G.722.1)
Screen Size NOT Support
RAM 128 MB
ROM 32 GB by default
IR Range NOT Support
Wi-Fi Protocol 802.11b/g/n
Positioning Mode GPS
Cellular Network Only available for models with /GLE，LTE FDD B1/3/5/7/8/20， LTE TDD B38/40/41
Wi-Fi Frequency Band 2.412 to 2.472 GHz
Protocol HTTPS, RTSP, NTP
API ISUP 5.0,SDK,ISAPI
USB 1 Type-C USB 2.0 port(s)
Indicator 4 Indicator(s) for Charging/Working/Recording/Wifi/4G
Button 4, (Power, Wi-Fi,SOS,Recording)
Operating System Linux
Power 5 VDC, 2 A, max. 10 W
Operating Condition Temperature: -20 °C to +55 °C (-4 °F to +131 °F) Humidity: 90% or less (non-condensing)
Dimensions 70 mm × 52 mm × 21 mm (2.75" × 2.04" × 0.82")
Weight 110g (0.24 lb.)
MIC Supported
Speaker Supported
Client Hik-Connect,HikCentral Pro,HikCentral Master,HikCentral Master Lite
Capacity 2500 mAh
Battery Type Lithium-ion battery, integral
Charging Time ≤ 3 h
Battery Duration approx 13 h in 720p resolution
RF EN 301 489-1V2.2.3,EN 301 489-17V3.2.4,EN 300 328V2.2.2
EMC EN 55032: 2015+A11:2020+A1:2020, EN IEC61000-3-2: 2019+A1:2021, EN 61000-3-3: 2013+A1:2019+A2:2021, EN 50130-4: 2011+A1: 2014
Safety CB: IEC 62368-1: 2014+A11,IEC 62368-1: 2018,CE-LVD: EN 62368-1: 2014/A11: 2017,EN IEC 62368-1:2020+A11:2020,CE-LVD: EN 62368-1: 2014/A11: 2017
Environment CE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
Warranty 2 years for the device, 1 year for the battery

Dokümanlar

Data Sheet - Civil Body Video Camera
