Hikvision DS-MCC216

Markaya göre filtrele

Hikvision DS-MCC216
Hikvision

Hikvision DS-MCC216

Model kodu
DS-MCC216
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

With low power consumption, 2.13" electronic ink screen provides clear display effect in daytime and manual configuration of the digital nameplate information.. Light and small. Approx. 52 g (0.1 lb., without back plate) and comfortable to wear.. Supports Wi-Fi connection, live view and control via mobile App.. Wearable with the magnet or pin.. Data loss prevention function: If the battery is low when recording, the device will automatically save the recorded data before shutting down.

Teknik özellikler

Image Sensor 1/2.9" progressive scan CMOS
Max. Resolution 1600 × 1200
Focal Length 1.36 mm fixed lens
FOV Horizontal FOV: 91° Vertical FOV: 74° Diagonal FOV: 115°
Aperture F2.2
Video Format PS, MP4
Video Compression H.264, H.265
Main Stream 60 Hz: 30 fps (1600 x 1200, 1280 x 960, 640 × 480)
Audio Compression for Video Recording G722_1,AAC
Audio Bit Rate G722_1(16 kbps) ,AAC(64 kbps)
Image Format JPEG
Screen Size 2.13"
Resolution 122 × 250; ink screen
RAM 128 MB
ROM 32 GB; 64 GB optional
Wi-Fi Frequency Band 2.412 to 2.472 GHz
Wi-Fi Protocol 802.11 a/b/g/n
Protocol HTTPS, RTSP, NTP, FTP
API ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
Indicator 2 Indicator(s) for Charging/Working/Recording/Exception/Wifi
Button Power, Wi-Fi
Charging Interface Type-C
USB USB 2.0
Operating System Linux
Power 5 VDC, 2.0 A, max. 10 W
Client Hik-Connect, HikCentral Pro, HikCentral Master Lite
Operating Condition Temperature: -20 °C to +55 °C (-4 °F to +131 °F) Humidity: 90% or less (non-condensing)
Dimension 81 mm × 32.4 mm × 9 mm (3.2" × 1.3" × 0.4")
Weight 52 g (0.1 lb., without back plate)
MIC Supported
Battery Duration Up to 8 h in 720p resolution¹
Capacity 1550 mAh
Battery Type Lithium-ion battery, integral
Charging Time ≤ 3 h
RF EN 300 328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G)
EMC CE-EMC: EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014
Safety CB: IEC 62368-1: 2014+A11, IEC 62368-1: 2018 CE-LVD: EN 62368-1: 2014/A11: 2017, EN IEC 62368-1:2020+A11:2020
Environment CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Warranty 2 years for the device, 1 year for the battery

Dokümanlar

Quick Start Guide - Nameplate Camera with Screen

Bu ürünü satan firmalar

1 firma
TESAN İLETİŞİM A.Ş
Bahçelievler, İstanbul
