Hikvision DS-MCH508D

Markaya göre filtrele

Hikvision DS-MCH508D
Hikvision

Hikvision DS-MCH508D

Model kodu
DS-MCH508D
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Up to 1080p/30 fps recording resolution. H.264/H.265. IR light supplement. Wide-range lens with 102° horizontal FOV. IP67. The battery is dismountable. Rotatable lens to adjust angle (± 90°)

Teknik özellikler

CPU Single core, 32 bit, Main frequency: 0.96 GHz
Max. Recording Resolution 1920 × 1080
Image Sensor 1/2.8"" progressive scan CMOS
Min. Illumination Color: 0.03 Lux @ (F2.4, AGC ON), 0 Lux with supplement light
Day & Night Switch IR cut filter automatically
Zoom Not supported
Focal Length 2 mm fixed lens
FOV Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 124°
Aperture F2.4
Video Compression H.264,H.265
Main Stream 30 fps (1920 × 1080, 1280 × 720, 720 × 576)
Sub-Stream 30 fps, 15fps, 5fps(1280 × 720, 720 × 576)
Video Format PS，MP4
Audio Compression for Video Recording G722_1,AAC
Audio Compression for Group Intercom G711_A,G711_MU,G722_1
Audio Bit Rate G711_A(64 kbps) ,G711_MU(64 kbps),G722_1(16 kbps) ,AAC(64 kbps)
Image Format JPEG
Image Resolution 5 MP, 16 MP, 30 MP, 40 MP
Image Stabilization Algorithm Not supported
Screen Size 0.88"
Display Resolution 128 × 32
Screen Brightness Typical value: 150 cd/m²
Capacity 32 GB eMMC
RAM 128MB
IR Range Up to 10 m
IR Wavelength 940 nm
Bluetooth BT4.0
Wi-Fi Protocol IEEE 802.11 b/g/n
Positioning Mode GPS
Cellular Network Only available for models with /GLE: GSM: 850/900/1800/1900 WCDMA: B1/B8 FDD -LTE: B1/B3/B5/B7/B8/B20/B28 TDD -LTE: B38/B40/B41
NFC Not supported
Protocol HTTPS, RTSP, NTP, FTP
API ONVIF (PROFILE S, PROFILE G, PROFILE T),ISAPI,SDK,ISUP 5.0
Encryption AES128 / AES256
Watermark Supported
USB 1 USB 2.0 port(s)
Indicator 1 Dual color Indicator for Charging/Working/Recording/Exception
Button Power,Fn
SIM Card Only available for models with /GLE :1 (Nano-SIM)
Charging Interface Type-C
Smart Event Fall detection
Group Intercom Not supported
Operating System Linux
Power 5 VDC, 2 A, max. 10 W
Vibration Motor Supported
Operating Condition -20 °C to 55 °C (-4 °F to 131 °F). Humidity 95% or less (non-condensing)
Dimensions 94 mm × 54 mm × 48 mm (3.7" × 2.3" × 1.9")
Weight 233 g (without mounting) (0.51 lb.)
MIC Supported
Gyroscope Supported
Speaker Not supported
Capacity 2700 mAh
Battery Type Lithium-ion battery, dismountable
Charging Time ≤ 4 h
Battery Duration Up to 11h in 720p resolution¹
RF EN 301489-1 V2.2.3 EN 301489-3 V2.1.1 EN 301489-17 V3.2.4 EN 301489-52 V1.2.1 EN 301 489-19 V2.2.1 EN 300328 V2.2.2 EN 303413 V1.2.1 EN 300330 V2.1.1 EN 50360:2017 EN 50566:2017 EN 300 440 V2.1.1 EN 301908-1 V15.1.1 EN 301 908-13 V13.1.1
EMC EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011+A1: 2014
Safety CB: IEC 62368-1: 2014+A11, IEC 62368-1: 2018 CE-LVD: EN 62368-1: 2014/A11: 2017
Environment CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection IP67
Drop Test MIL-STD-810G, 2 m drop test
Warranty 2 years for the device without battery, 1 year for the battery

Bu ürünü satan firmalar

1 firma
TESAN İLETİŞİM A.Ş
Bahçelievler, İstanbul
