Hikvision DS-MCW407(C)

Markaya göre filtrele

Hikvision DS-MCW407(C)
Hikvision

Hikvision DS-MCW407(C)

Model kodu
DS-MCW407(C)
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

2K recording.. The recorded videos can be uploaded to the central video platform via 4G wireless communication.. Supports IR night vision. Even in the dark scene, the facial features of the persons in the scene can be recognized clearly.. Tri-proof design to support all-weather filed operation.. Built-in battery with large capacity, supporting longer working hour.. Small size, light weight, and convenient to carry.. Large recording button for convenient operation.

Teknik özellikler

Image Sensor 1/3" progressive scan CMOS
Max. Recording Resolution 2688 × 1512
Min. Illumination Color: 0.11 Lux @ (F2.2, AGC ON), 0 Lux with supplement light
Day & Night Switch IR cut filter automatically
Zoom 4x Digital
White Light 1 white light(s)
Focal Length 2.4 mm fixed lens
FOV Horizontal FOV: 126°, Vertical FOV: 70°, Diagonal FOV: 144°
Aperture F2.2
Video Compression H.264,H.265
Video Format MP4,PS
Main Stream 60 Hz: 30 fps (2688 ×1512, 1920 × 1080, 1280 × 720, 720 × 576)
Sub-Stream 30 fps(1920 × 1080, 1280 × 720, 720 × 576)
Pre-record & Post-record Pre-record: 60/10/5/3 s, Post-record: 60/10/5/3 s
Audio Compression for Video Recording G722,AAC
Audio Compression for Audio Recording PCM
Audio Compression for Group Intercom G711.A,G711.U,G722
Audio Bit Rate G722(16 kbps) ,AAC(dynamic),PCM(256 kbps),G711.A(64 kbps) ,G711.U(64 kbps)
Image Format JPEG
Display Resolution 320 × 240
Screen Size 2.0"
Touchscreen Supported
RAM 2 GB
ROM 64 GB by default, 128/256 GB optional
IR Range Up to 10 m
IR Wavelength 850 nm
Bluetooth BT4.2
Wi-Fi Protocol 802.11 a/b/g/n/ac
Wi-Fi Frequency Band 2.412 to 2.472 GHz,5.15 to 5.25 GHz,5.725 to 5.875 GHz
Cellular Network Only available for models with /GLE:, GSM: 850/900/1800/1900,WCDMA: B1/B8,FDD -LTE: B1/B3/B4/B7/B20/B28,TDD -LTE: B34/B38/B39/B40/B41
Positioning Mode GPS
Protocol HTTPS, RTSP, NTP, FTP
API ONVIF (PROFILE S, PROFILE G, PROFILE T),ISAPI,SDK,ISUP
Indicator 2 indicator(s) for charging/working/recording/exception
Button Power,Video recording,Audio recording,Picture capture,PTT,SOS,Fn
Audio Type 1 built-in mic(s),1 speaker(s)
SIM Card Only available for models with /GLE /5G:, 1 Nano-SIM card(s)
Charging Interface Type-C, Pogo Pin
USB 1 USB 2.0 port(s)
Operating Condition -20 °C to 55 °C (-4 °F to 131 °F). Humidity 95% or less (non-condensing)
Power 5 VDC, 2.0 A, max. 10 W
Dimensions 82.6 mm × 58 mm × 29 mm (3.3" × 2.3" × 1.1")
Weight 165 g (without mounting) (0.4 lb.)
Operating System Android 9.0
Client HikCentral Pro,HikCentral Master
MIC Supported
Speaker 1 built-in speaker(s), max. power consumption: 1 W, max. sound pressure level: 87 dB (10 cm)
Battery Type Lithium-ion battery, integral
Capacity 3220 mAh
Charging Time ≤ 4 h
Battery Duration Up to 12 h in 720p resolution¹
RF EN 300 328 V2.1.1 (BT or 2.4G),EN 62311:2008 (BT or 2.4G),EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:2013,EN 50130-4:2011+A1:2014)
EMC CE-EMC: EN 55032: 2015,EN 61000-3-2: 2019,EN 61000-3-3: 2013,EN 50130-4: 2011 +A1: 2014
Safety CB: IEC 62368-1: 2014+A11,IEC 62368-1: 2018,CE-LVD: EN 62368-1: 2014/A11: 2017,EN IEC 62368-1:2020+A11:2020,CE-LVD: EN 62368-1: 2014/A11: 2017
Environment CE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
Protection IP68: IEC 60529-2013,MIL STD 810G

Dokümanlar

Data Sheet - Android 4G Big Button Body Camera
