Hikvision DS-MDS004

Markaya göre filtrele

Hikvision DS-MDS004
Hikvision

Hikvision DS-MDS004

Model kodu
DS-MDS004
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Small size and easy to place. Fan-free and silent design.. Supports accessing to 8 nameplate cameras simultaneously and auto charging of the nameplate camera.. Adopts the web client to display data collection and parameters configuration.. Supports auto uploading of the nameplate camera data, and clearing the storage space of the nameplate camera automatically.. Data overwriting: The collected data will be overwritten according to the collection order when the storage is full.. ANR (Automatically Network Replenishment) for data uploading to prevent data loss.. Supports searching files by multiple methods. Supports playing videos, audios, and images.

Teknik özellikler

HDD Up to 2 disks (Max. 8 TB for each disk) and default 2 TB
RAM 1 GB
Protocol HTTPS, RTSP, NTP, FTP
API ISAPI, ISUP
Body Camera Up to 8 body cameras or 8 nameplate cameras
Indicator 1 power indicator, 1 hard disk indicator, 1 network indicator, 8 status indicators (for charging and data transmission status)
Button Power
Ethernet 2 RJ45 10M/100M/1000M self-adaptive ethernet port(s)
USB USB 2.0
Charging Interface Type-C
Base 5 VDC, 1.5 A for each channel, backup speed ≥ 8 MB/s
General 1 RS-232, 1 power supply
HDMI x1
Operating Condition -10 °C to 55 °C (14 °F to 131 °F). Humidity 95% or less (non-condensing)
Operating System Linux
Web Browser Plug-in required live view: IE 10+Plug-in free live view: Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+
Client HikCentral Pro, HikCentral Master
Speaker 1 Built-in speaker, Max. power consumption: 5.5 W, Max. sound pressure level: 79dB (11 cm)
Installation Method Desk-Mounted
Power 12 VDC, 10.0 A, max. 120 W
Dimension 265 mm × 230 mm × 60 mm (10.43" × 9.06" × 2.36")
Weight 2.84 Kg (without Hard Disk) (6.3 lb.)
EMC CE-EMC: EN 55032: 2015+A1: 2020, EN IEC 61000-3-2: 2019+A1: 2021, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014
Safety CB: IEC 62368-1: 2014 CE-LVD: EN 62368-1: 2014+A11: 2017
Environment CE-RoHS: 2011/65/EU
