Ürün açıklaması
Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.
Adopts integrated machine core. Parallel gear decelerates linkage arm transmission to ensure stability and efficiency.. Supports convenient side installation with compact structure.. Adopts quenching process for carbon steel gear to realize wear-resistant and impact-resistant functions and extend product life.. Adopts small DC brushless motor with low noise to increase output torque and realize precise intelligent control.. Supports rebound for obstacle and opening priority.. Adopts DC variable frequency control to enable smooth operation with fast boom pole opening and slow boom pole closing.. Supports event log to enable convenient monitoring.. Supports multiple anti-fall modes such as IR, vehicle detectors, and radars.. Supports fault code detection on the nixie tube, log record, and abundant status indicating. Based on the fault code displayed on the nixie tube, you can realize quickly problems locating and maintenance.. Supports manually opening boom pole. You can turn hand wheel to keep barrier gate opening during power cutoff.. Delayed boom pole closing (10 s delay time by default). Supports 99 shifts (initial status 2 s, 2 s gap between each shift).. Supports auto boom pole opening during power cutoff. The barrier gate can open automatically to allow fire trucks in (optional components required).. Intergated with body indicator to show barrier gate status
Teknik özellikler
| Barrier Housing Material | SGCC |
|---|---|
| Barrier Housing Thickness | 1.5 mm |
| Barrier Housing Door Thickness | 1.2 mm |
| Barrier Housing Color | Iron gray |
| Barrier Housing Door Color | Orange red |
| Boom Pole Installation Height | 885 mm |
| Body Indicators | With body indicator. Green: arrow indicator. Red: passing prohibition indicator. |
| Rising Speed | 4m: 3s |
| Falling Speed | 4m: 3s |
| Boom Pole Direction | DS-TMG423-L/B: Left DS-TMG423-R/B: Right |
| Motor Type | DC brushless motor |
| Matched Boom Pole Type | Fence boom pole |
| Boom Pole Falling Delay | 10 s by default (configurable), min. 2 s (every 2 s followed a gap) |
| Number of Cycles | 5,000,000 |
| Working Voltage | 100-120VAC / 200-240VAC (default 220-240V，switchable) |
| Consumption | Max. 176 W |
| Temperature and Humidity | Temperature: -30 °C to 60 °C (-22 °F to 140 °F),Humidity: ≤ 90% |
| Rising Boom Pole for Poweroff | Optional, not supported by default |
| Duty Cycle | 100% |
| RS-485 | 1 group |
| Rising to Limit | 1 group |
| Falling to Limit | 1 group |
| Open | 1 group |
| Close | 1 group |
| Stop | 1 group |
| IR/Vehicle Detector/Radar | 1 group |
| Traffic Signal Light | 1 group, external power supply required, max. 220 VAC supported |
| Boom Pole Color | White background with red bar |
| Boom Pole Weight | 9.65 ± 0.3 kg (21.27 ± 0.66 lb.) |
| Boom Pole Dimensions (with Package) | 4 m: 230 × 90 × 4300 mm (9.06 × 3.54 × 169.29 inch) |
| Boom Pole Weight (with Package) | 4 m: 11.34 ± 0.3 kg (25 ± 0.66 lb.) |
| Boom Pole Dimensions | 4 m: 1261.5 × 92.5 × 4000 mm (49.67 × 3.64 × 157.48 inch) |
| Boom Pole Material | AL6061 |
| RF | CE-RED EN 300220-1 V3.1.1 EN 300220-2 V3.1.1 EN 301489-1 V2.2.3 EN 301489-3 V2.1.1 EN IEC 62311: 2020 |
| EMC | CE-EMC： EN 55032: 2015/A11: 2020 + A1: 2020, EN IEC 61000-3-2: 2019/A1: 2021, EN 61000-3-3: 2013 + A1: 2019/A2: 2021, EN 50130-4: 2011+A1: 2014 |
| Security | CE-LVD: EN 62368-1: 2014/A11: 2017 CB: IEC 62368-1: 2014 IEC 62368-1: 2018 |
| Environment | ROHS |
| Protection | IP54, IK09 |
| Barrier Housing Dimensions (L × W × H) | 1060 × 370 × 262 mm (41.73 × 14.57 × 10.31 inch) |
| Body Weight | 43 ± 3 kg (94.8 ± 6.61 lb.) |
| Body Dimensions (with Package, Without Boom Pole) (L × W × H) | 1266 × 504 × 626 mm (49.84 × 19.84 × 24.65 inch) |
| Body Weight (with Package, Without Boom Pole) | 47 ± 3 kg (103.61 ± 6.61 lb.) |
