Hikvision HikCentral-Workstation/HW5L/32Ch(C)

Markaya göre filtrele

Hikvision HikCentral-Workstation/HW5L/32Ch(C)
Hikvision

Hikvision HikCentral-Workstation/HW5L/32Ch(C)

Model kodu
HikCentral-Workstation/HW5L/32Ch(C)
Sistem
Kamera sistemi

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

The tower workstation combines powerful functions with a compact design, which can be used as a server and control client at the same time. 1) Four-screen independent output for efficient management. 2) Integrated GPU supports great decoding capability. All-in-one software and hardware, no activation required, easy delivery and reliable service.. 1) Guaranteed compatibility: Tested by professional testing team to ensure stable operation. 2) Reliable after-sales service: 24/7 platinum after-sales service

Teknik özellikler

Video Management 32ch by default,can be expanded into 128ch (Including ANPR Cameras and Cameras with Face Capture Function)
Access Controls 4ch by default,can be expanded into 16ch (Including Doors and Outdoor Station)
Indoor Station Not included,can be expanded into 16
ANPR Cameras Not included,can be expanded into 16ch
Lanes of Entrance & Exit Not included,can be expanded into 16
Cameras with Face Capture Function Not included,can be expanded into 16ch
Alarm Panel Not included,can be expanded into 16
Smart Walls Not included
Attendance Not included,can be expanded by extra license
Storage of Events or Alarms without Pictures 10/s
Events or Alarms Sent to Clients 10/s，10 Client/s (Including Control Clients and Mobile Clients）
Picture Storage 10/s (Including event/alarm pictures, face pictures, and vehicle pictures)
Vehicle Passing Frequency in Each Lane 1 Vehicle/s
Data Retention Period Stored for 6 Months
4CIF (704*576)/H.264/1024 kbps * 30 fps Maximum Hardware Decoding Channels：62 Maximum Software Decoding Channels：42
4CIF (704*576)/H.265/512 kbps * 30 fps Maximum Hardware Decoding Channels：62 Maximum Software Decoding Channels：42
720P (1280*720)/H.264/2048 kbps * 30 fps Maximum Hardware Decoding Channels：42 Maximum Software Decoding Channels：24
720P (1280*720)/H.265/1024 kbps * 30 fps Maximum Hardware Decoding Channels：42 Maximum Software Decoding Channels：24
1080P (1920 × 1080)/H.264/4096 kbps * 30 fps Maximum Hardware Decoding Channels：32 Maximum Software Decoding Channels：16
1080P (1920 × 1080)/H.265/2048 kbps * 30 fps Maximum Hardware Decoding Channels：32 Maximum Software Decoding Channels：16
4 MP (2560 × 1440)/H.264/8192 kbps * 30 fps Maximum Hardware Decoding Channels：24 Maximum Software Decoding Channels：10
4 MP (2560 × 1440)/H.265/4096 kbps * 30 fps Maximum Hardware Decoding Channels：24 Maximum Software Decoding Channels：10
8 MP (3840 × 2160)/H.264/16384 kbps * 30 fps Maximum Hardware Decoding Channels：12 Maximum Software Decoding Channels：5
8 MP (3840 × 2160)/H.265/8192 kbps * 30 fps Maximum Hardware Decoding Channels：12 Maximum Software Decoding Channels：5
6 MP (2560 × 2560) /H.264/12288 kbps * 30 fps Maximum Hardware Decoding Channels：18 Maximum Software Decoding Channels：8
6 MP (2560 × 2560) /H.265/6144 kbps * 30 fps Maximum Hardware Decoding Channels：18 Maximum Software Decoding Channels：8
12 MP (4000 × 4000)/H.264/16384 kbps * 20 fps Maximum Hardware Decoding Channels：10 Maximum Software Decoding Channels：4
12 MP (4000 × 4000)/H.265/8192 kbps * 20 fps Maximum Hardware Decoding Channels：10 Maximum Software Decoding Channels：4
CPU i5-12500， 3.00 GHz, 18 MB Cache， 6 Cores, 12 Threads
Memory Standard Config：2 × 8GB UDIMM，3200MT/s Scalability：4 × 32GB UDIMM
Hard Disks Standard Config：1 × 1TB M.2 SSD Scalability：1 × 4TB 3.5inch SATA HDD
Supported Operating Systems Win10 multilingual version pre-installed
Graphic Card Standard Config：UHD Graphics 770（intergrated in CPU） Scalability：1 × Semi-high Independent graphics card（Please contact technical support for more info.）
PCIe Slots 1*PCIe 4.0 x16 Slot 1*PCIe 4.0 x4 Slot
Type-C 1
USB 3.0 1（Front）+3（Rear）
USB 2.0 2（Front）+2（Rear）
Universal Audio Port 1
Ethernet Port 1 x LAN 10/100/1000
VGA /（HDMI port can be used as VGA port）
HDMI 1
DP 3（DP port can be used as HDMI port）
Net Weight 5.63 kg (12.42 lb)
Gross Weight 6.72 kg (14.81 lb)
Dimension (W × H × D) 92.60 mm × 290.00 mm × 292.80 mm (3.65'' × 11.42'' × 11.53'')
Package Dimensions (W × H × D) 394.00 mm × 264.00 mm × 487.00 mm (15.51'' × 10.39'' × 19.17'')
Operating Temperature 5 °C to 45 °C (41 °F to 113 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity 20% to 80% (no condensation)
Storage Humidity 5% to 95% (no condensation)
Power Supply 300 W PSU，92% Energy efficiency，80 Plus Platinum
Form Factor Tower SFF
