Hikvision iDS-9632NXI-M8/AI(B) - NVR kayıt cihazı
Hikvision

Hikvision iDS-9632NXI-M8/AI(B) - NVR kayıt cihazı

Model kodu
iDS-9632NXI-M8/AI(B)
Sistem
Kamera sistemi
Kategori
NVR kayıt cihazı

Ürün açıklaması

Türkçe çevirisi hazırlanıyor, şimdilik üretici sitesindeki İngilizce metin gösteriliyor.

Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080p decoding capacity. H.265+/H.265/H.264+/H.264 video formats. Up to 32-ch IP cameras can be connected. Deep learning based video analytics for not wearing hard hat detection and event detection, including people running detection, people gathering detection, violent motion detection, using mobile phone detection, etc

Teknik özellikler

AI by NVR Pre-installed AI Algorithm Package Human (3 Algorithm models ) 1. Facial recognition: 2. People counting: regional people counting, people counting statistics 3. PPE: safety helmets and reflective vests detection Vehicle (2 Algorithm models ) 1. Vehicle attributes: vehicle brand,vehicle color, vehicle type 2. Non-motorized vehicle detection: motorcycle, bicycles Dangerous Event (2 Algorithm models ) 1. Fire and smoke detection 2. Occupation of fire escape Behavior (3 Algorithm models ) 1. Street level behavior : falling down detection, people gathering detection, fast moving detection, physical conflict detection 2. Indoor: playing phone, sleeping on duty, absence, number of people allowed, overstaying detection 3. Perimeter: intrusion detection, line crossing detection, region entrance detection, region exiting detection 4. Smoke detection, call detection AIOP (Up to 16 models) Model type: detection model, classification model, mixed model (detection model and classification model) 1 engines in total, One engine can support four algorithm models; each algorithm model supports one real-time video stream analysis or a maximum of 8 auto-switch video analyses (switch time between 10 to 3600 seconds)
Engine 3 * KT2 (2 for live video analysis, 1 for lager model algorithm secondary analysis)
Live Video Analysis 2 engines in total,one engine can support up to 4ch,(4ch@4MP，2ch@6MP，1ch @8MP)
Auto-Switch Video Analysis 2 engines in total,one engine can support up to 16ch,(switch time between 10 to 3600 seconds)
Scheduled Capture Analysis 2 engines in total,one engine can support up to 16ch, (switch time between 3 to 3600 seconds)
Offline Picture Analysis 4 image per GPU per second or 1 image per GPU per second ( Large model)
IP Video Input 32-ch
Incoming Bandwidth 320 Mbps
Outgoing Bandwidth 400 Mbps
HDMI 1 Output HDMI1：8K (7680 × 4320)/30 Hz, 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1080P (1920 × 1080)/60 Hz *: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p.
HDMI 2 Output HDMI2：4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz
VGA 1 Output 1080P (1920 × 1080)/60 Hz
VGA 2 Output 1080P (1920 × 1080)/60 Hz
Video Output Mode HDMI1/VGA1 simultaneous output, HDMI2/VGA2 simultaneous output
Audio Output 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding Format H.265/H.265+/H.264/H.264+
Decoding Capability Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080P
Synchronous Playback 16-ch
Recording Resolution 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF *: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Remote Connection 128
Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
API ONVIF (profile S/G); SDK; ISAPI
Compatible Browser IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
Network Interface 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
RAID Type RAID0, RAID1, RAID5, RAID6, RAID10
Ctrl 12V Controllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered. *: The Ctrl 12V power is controlled by alarm output 9.
DC 12V 12 VDC, 1 A power output
SATA 8 SATA interfaces; 3.5-inch HDD
eSATA 1 eSATA interface
Capacity Up to 16 TB capacity for each HDD
Serial Interface 1 RS-232, 1 RS-485 (full-duplex)
USB Interface Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0
Alarm In/Out 16/9
GUI Language English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
Power Supply 100 to 240 VAC, 50 to 60 Hz
Consumption ≤ 50 W (without HDD)
Working Temperature -10 to 55° C (14 to 131° F)
Working Humidity 10 to 90%
Dimension (W × D × H) 442 × 460 × 88 mm
Weight ≤ 9 kg (without HDD)

Dokümanlar

Data Sheet - NVR DeepinMind User Manual - NVR DeepinMind
